PARTS LIST CONTROL MODULES
M3, M3K, M3L, M3P
M3O
MS
I TEM
D ESCRIPTION
Q TY
PART NO
Diaphragm/Gasket Kit
75-1107
(M3, M3K, M3L, M3P)
Above Kit Consists of:
1
Diaphragm
1
75-0716
2
Lower Gasket (thick)
1
75-0426
3
Upper Gasket (thin)
1
75-0636
4
Follower O-ring
1
75-0337
5
Fiber Washer
1
75-0617
6
Lower Stem O-ring (green dot)
1
75-0520
7
Upper Stem O-ring
1
75-0521
8
Seal Cap O-ring
1
70-0011
* M3W and M3KW control modules are hermetically sealed,
welded assemblies having no replaceable internal parts. See
page 6 for replacement part numbers. Standard on ¾"–1¼"
(20–32 mm) valves.
I TEM
DESCRIPTION
QTY
PART NO
Diaphragm/Gasket Kit (M3O)
75-1108
Above Kit Consists of:
1
Diaphragm
1
75-0716
2
Lower Gasket (thick)
2
75-0426
3
Upper Gasket (thin)
1
75-0636
4
Follower O-ring
1
75-0337
5
Fiber Washer
1
75-0617
6
Lower Stem O-ring (green dot)
1
75-0520
7
Upper Stem O-ring
1
75-0521
8
Seal Cap O-ring
1
70-0011
9
Cartridge O-ring
1
75-0496
ITEM
DESCRIPTION
QTY
PART NO
Solenoid Tube/Plunger Kit (MS)
70-1059
Above Kit Consists of:
1
Coil Washer
1
70-0289
2
Coil Nut
1
70-0281
3
Plunger
1
70-0295
4
Solenoid Tube
1
70-0298
5
Solenoid Tube Gasket
1
70-0301
6
Tube Screws
4
70-0297
R429d
14
MAR 2002
