3 ESL ACCESS POINT INSTALLATION
3.1.1 Installation requirements
In actual use, the ESL Access Point should be installed in a higher position to achieve better
transmission and coverage, as shown in Figure 3-1.
Figure 3-1 ESL Access Point installation diagram
Note: the H in the diagram, is suggested to be between 3 to 3.5 meters to cover a area of
raduis of 15 meters
3.1.2 Accessories
Figure 3-2 ESL Access Point installation accessories diagram
Figure 3-2 is the ESL Access Point standard installation accessories structure; recommend the
use of hanging installation, the assembly diagram shown in Figure 3-3.
