Figure7-1ESL Access Point package
7.2 Pack Contents
Package includes: 1 ESL Access Point, 4 white antennas, 1 AC-DC 12V power adapter, 1
mounting kit and 5 screws.
8 NOTICE OF PERATION
8.1 Installation
Caution
Please use the standard power adapter;
Installation height of 3 to 3.5 meters;
ESL Access Point covers a radius of 15 meters;
ESL Access Point to avoid placing metal interference around the periphery. In particular
the need to avoid the formation of cage-like interference effects;
ESL Access Point installation must be firmly installed to avoid loose off.
