ESL Access Point HS_C09851 PRODUCT MANUAL
Page 6 , Total 15
2.2 Configuration and Appearance
2.2.1 Basic Configuration
HS_C09851 Configuration
Power Module
Input voltage
12V DC
Rated current
1A
Rated power
12W
Other
Overload / overvoltage / over temperature protection
Host Processor Module
CPUFreq.
720MHz ARMprocessor
Storage
512M FLASH + 512M RAM
OS
Embedded Linux system
RF（2.4G Module）
Working Freq.
2.402～2.480GHz
Channel bandwidth
500KHz
Modulation
GFSK
Transmission rate
Uplink：500K bps Downlink：100K bps
Antenna gain
0dBi（selectable）
Antenna feature
4-
Rod antenna
Super-high sensitivity
-95dBm at 500Kbps
-97dBm at 100Kbps
Ethernet Module
Rate
100M（adaptive）
Self-negotiation
Support
Auto MDI/MDI-X
Support
DHCP
Support
POE Module
Input voltage
36 ~ 57V DC
Output voltage
12V
Current
1A
Max power
12W
