Model
Model Channels Max.Frequency
CH1/CH2
Sampling Rate
CH3
Sampling Rate
HDG3012B 2 15MHz 300MS/s -
HDG3022B 2 25MHz 300MS/s -
HDG3042B 2 40MHz 300MS/s -
HDG3062B 2 60MHz 300MS/s -
HDG3082B 2 80MHz 300MS/s -
HDG3102B 2 100MHz 300MS/s -
HDG3013C 3 15MHz 300MS/s 150MSa/s
HDG3023C 3 25MHz 300MS/s 150MSa/s
HDG3043C 3 40MHz 300MS/s 150MSa/s
HDG3063C 3 60MHz 300MS/s 150MSa/s
HDG3083C 3 80MHz 300MS/s 150MSa/s
HDG3083C 3 100MHz 300MS/s 150MSa/s
Format Conventions in this Manual
Keys
The keys on the front panel are usually denoted by the format of "Key Name (Bold) + Square
Brackets (Bold)". For example, [Utility].
User Manual 5
