BlackmanH BlackmanH window
BohmanWin
Bohman window
Boxcar
Rectangle window
ChebWin
Chebyshev window
FlattopWin
Flat Top weighted window
Hamming Hamming window
Hanning Hanning window
Kaiser Kaiser window
NuttallWin Nuttall-defined minimum 4-term Blackman-Harris window
ParzenWin Parzen window
TaylorWin Taylor window
Triang
Triangle window (Fejer window)
TukeyWin
Tukey (tapered cosine) window
User-definedWaveforms
Select the user-defined arbitrary waveform stored in external storage (USB drive).
Loading arbitrary waveform
Edit the ARB waveformby PC software and exportthe waveform data to the external storage
device as .hwf file.
Press [Wave] >Arb softkey to enter the arbitrary menu, and press Type >User softkeyto select
the arbitrary waveform file to load.
User Manual 29
