Frequency
PM
Carrier
Waveforms
Sine, Square, Ramp, Pluse, Harmonic, Arb. (except DC)
Modulation
Source
Internal, External, another channel
Modulation
Waveforms
Sine, Square, Ramp, Noise,
Sinc, Exp Fall, Haver Sine, Lorentz, Gause, Dual
Tone, ECG
Modulation
Frequency
2mHz~1MHz
Phase
Deviation
0 ° ~ 360 °
ASK
Carrier
Waveforms
Sine, Square, Ramp, Pluse, Harmonic, Arb. (except DC)
Modulation
Source
Internal, External
Modulation
Waveforms
Square with 50% duty cycle
Rate 2mHz~1MHz
FSK
Carrier
Waveforms
Sine, Square, Ramp, Pluse, Harmonic, Arb. (except DC)
Modulation
Source
Internal, External
Modulation
Waveforms
Square with 50% duty cycle
Rate
2mHz~1MHz
PSK
Carrier
Waveforms
Sine, Square, Ramp, Pluse, Harmonic, Arb. (except DC)
Modulation
Source
Internal, External
Modulation
Waveforms
Square with 50% duty cycle
Rate 2mHz~1MHz
BPSK
Carrier
Waveforms
Sine, Square, Ramp, Pluse, Harmonic, Arb. (except DC)
Modulation
Data Source
PN15, PN21, 01, 10
