Hantek HDM3000 User Manual

85
AC Current Gain and Flatness Calibration
Configuration: AC current
1. Configure the ranges shown in the following table.
2. Apply the input signal shown in the Input column.
3. Input the input current range for the actual application.
The message Calibration
Step Succeeded indicates success.
If the display shows Calibration Step Failed,
check the input value, range, function, and the input calibration value and repeat the
calibration steps.
4. Repeat steps 1 to 3 for each frequency shown in the table.
5. Repeat steps 1 to 4 for each current range shown in the table.
61/2 DMM calibration points are as follows:
Range linearity calibration
gear
Calibration
point 1
Calibration
point 2
Calibration
point 3
100uA
100uA@1KHz
100uA@10KHz
1mA
1mA@1KHz
1mA@10KHz
10mA
10mA@1KHz
10mA@10KHz
100mA
100mA@10Hz
100mA@1KHz
100mA@10KHz
1A
1A@1KHz
1A@10KHz
3A
3A@1KHz
3A@10KHz
10A
10A@1KHz
10A@10KHz
51/2 DMM calibration points are as follows:
Range linearity calibration
gear
Calibration
point 1
Calibration
point 2
100uA
30uA@1KHz
100uA@1KHz
1mA
0.2 mA @ 1
KHZ
1mA@1KHz
10mA
2mA@1KHz
10mA@1KHz
100mA
20mA@1KHz
100mA@1KHz
1A
0.2 A @ 1
KHZ
1A@1KHz
3A
0.6 A @ 1
KHZ
3A@1KHz
10A
2A@1KHz
10A@1KHz
Frequency Accuracy Calibration
