Harbinger HP112 - Page 12

Owner’s Manual for models HP112 • HP115 • HP215 • HP118S
10
Checklist
•
Make certain loudspeakers are Powered
OFF
and Levels
turned down.
•
Connect the Mixer’s Main Left Output to the Left Input of
the subwoofer.
•
Connect the Mixer’s Main Right Output to the Right Input of
the subwoofer.
•
Connect the HP118S HP Output L to the Input of the Left
Main Speaker.
•
Connect the HP118S HP Output R to the Input of the Right
Main Speaker.
•
Set the Low Cut switch on the HP Series Main Speaker to OFF.
•
Power
ON
Mixer, then Power
O
N
speakers.
•
Bring the Mixer’s volume up to normal operating level.
•
Adjust the Level controls on the HP series loudspeakers.
•
Do not adjust the Level so high that the Red LIMIT LED is
constantly lit.
Stereo Main HP Speakers (HP112, HP115, HP215) with Single HP118S Subwoofer
MAIN OUTPUT
LR
