10
LP9800
POWERED MIXER
LP9800 Owner's Manual
FRONT PANEL
27
DSP Program
This knob is used to select the 16 preset FX programs from the built-in
24-bit DSP FX processer. Turn the knob to the desired FX preset.
DSP 24-BIT FX PRESET TABLE
NO. PRESET PARAMETER
1 Plate 1 Reverb Delay Time: 50ms
2 Room 1 Decay Time: 50ms
3 Plate 2 Reverb Delay Time: 50ms
4 Plate 3 Reverb Delay Time: 80ms
5 Room 2 Decay Time: 50ms
6 Room 3 Decay Time: 80ms
7 Hall 1 Decay Time: 50ms
8 Hall 2 Decay Time: 80ms
9 Delay 1 Delay Time: 100mS
10 Delay 2 Delay Time: 300mS
11 Flanger Decay Time: 50mS
12 Chorus Rate: 44.1K
13 Chorus/Room1 Rate: 22K
14 Chorus/Room2 Rate: 44.1K
15 Vocal Cancel
16 Rotary Speaker Modulation Depth: 6dB
26
Stereo-In Level
This is the volume level for any devices connected to the CD/AUX inputs. The sound from CD/MP3
IN goes directly to the MAIN Output.
