LP9800 Owner's Manual
SPECIFICATIONS
Power Amplifier (Output):
Input Channels
Microphone Inputs -60dBu
Frequency Response 20Hz-20KHz(±1dB)
Gain 36dB
Line Inputs -50dBu
Frequency Response 20Hz-20KHz(±0.5dB)
Gain 24dB
Impedance
Microphone Input 2.2KΩ balanced/ 1.1KΩ unbalanced
All Other Inputs 47KΩ unbalanced
Tape Out 120Ω
All Other Outputs 100Ω
Equalization
High Shelving 10KHz ±15dB
Mid Shelving 2KHz ±15dB
Low Shelving 60Hz ±15dB
Graphic EQ 65Hz/125Hz/250Hz/500Hz/1KHz/2KHz/4KHz/8KHz/16KHz (±12dB)
DSP section
A/D and D/A Converters YES
DSP Resolution 24BIT
Type of Effects AL3201
Presets YES
Controls encoder
Main Mix Section
Noise (Bus noise) ≤0.5mV
Monitor Max Out +21dBu
FX Sends Max Out +21dBu
Total Harmonic Distortion 1%
Signal to Noise Ratio 90dB
Static Power Consumption 50W
Power Source 115V-50/60Hz 230V-50Hz
