Harbor Freight Tools Central Pneumatic - PARTS LIST AND DIAGRAM; Parts List

Page 18 For technical questions, please call 1-800-444-3353. Item 60664
SAFETY OPERATION MAINTENANCESETUP
Part Description
1 Bolt M5 x 20
2 Exhaust Cap
3 Washer
4 Compression Spring
5 O-Ring
6 Cylinder Cap
7 Cylinder Cap Seal
8 Valve
9 O-Ring
10 O-Ring
11 O-Ring
12 O-Ring
13 Driver Blade Unit
14 O-Ring
15 Collar
16 O-Ring
17 Cylinder
18 Bumper
19 Body
20 Nozzle
21 Rubber Grip
22 O-Ring
23 End Cap
24 Air Inlet Plug
25 Air Plug Plug Cover
26 Sealing Gasket
27 Trigger Valve Seat
28 O-Ring
29 Trigger Valve Stem
30 O-Ring
31 Trigger Valve Guide
32 Spring
33 Trigger Lock
34 Trigger
35 O-Ring
36 Trigger Pin
37 Bolt M4 x 8
38 Cover Plate
Part Description
39 Bolt M5 x 16
40 Bolt M4 x 10
41 Drive Guide
42 Nut M4
43 Left Magazine
44 Adjusting Plate
45 Nail Length Adjusting Piece
46 Right Magazine
47 Bolt M4 x 10
48 Bolt M4 x 6
49 Left Regulator Shell
50 Nut M5
51 Left Support
52 Nut M4
53 Pin
54 Bolt M5 x 18
55 Right Support
56 Bolt M4 x 12
57 Bolt M3 x 4
58 Regulator Plate
59 Regulator Gear
60 Right Regulator Shell
61 Bolt M4 x 6
62 Steel Ball
63 Spring
64 Nail Length Adjusment Knob
65 Bolt M4 x 10
66 Magazine Cover
67 Pusher
68 Bushing
69 Pusher Guide
70 Pusher Spring
71 Magazine Lock
72 Spring
73 O-Ring
74 Pin
75 Rear Cover
76 Bolt
Parts List and Diagram
Parts List
