EF;6GH IJ6KFGLIM NFLMG6MFMO6FEE6NPQH
J,($ T*#4("/$"&8 d$U
1 7/32" Safety Chain 1
2 2" Coupler 1
3 Tow Bar T-Plate 1
4 Coupler Base 1
5 Tow Bar 2
6 Spring Plate 2
7 Axle 1
8 Leaf Spring 50 x 7 mm 2
9 Axle U-Bolt M10 x 90 and Nut M10 4
10 Grease Seal 2
11 Bearing 4
12 Hub Assembly 2
13 Tire 2
14 Washer 2
15 Castle Nut M22 x 1.5 2
16 Cotter Pin 2
17 Lug Nuts 10
18 Dust Cap 2
19 Left Spring Hanger 1
20 Hex Bolt M12 x 80 and Nut M12 6
21 Caster 4
22 Left Caster Bracket 1
23 Right Caster Bracket 1
24 Fender Bracket 2
J,($ T*#4("/$"&8 d$U
25 Fender 2
26 Front Left Side Rail 1
27 Front Hinge Plate 2
28 Rear Hinge Plate 2
29 License Plate Bracket 1
30R Right Tail Light 1
30L Left Tail Light 1
31 Rear Left Side Rail 1
32 Cross Member 5
33 Light Bracket 2
34 Rear Right Side Rail 1
35 Carriage Bolt M10 x 25 and Nut M10 4
36 Hex Bolt M10 x 30 and Nut M10 4
37 Front Right Side Rail 1
38 Side Running Light 2
39 Front Cross Member 1
40 Stake Bracket 8
41 Right Spring Hanger 1
42 Hex Bolt M12 x 25 and Nut M12 2
43 L Pin Ø12 x 75 and R-Clip 2
44 Hex Bolt M10 x 20 and Nut M10 78
45 Tow Bar Bracket 2
46 Screw and Nut 4
J,($#%Q"#$%,89%T",3(,5
JQ6FE6%K6FT%GX6%;IQQIRLMS%OFK6;WQQH
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
J,($#%Q"#$
K*4&(9%J(&9'4$a#%E*(",7%M'5+*(%X*(*-%
M&$*- If product has no serial number, record month and year of purchase instead.
M&$*- Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175444523 when ordering parts.
