Hardi ES 50 - Default Chapter; Table of Contents

2
HARDI
®
GAS ENGINE ESTATE SPRAYER OPERATOR’S MANUAL
TABLE OF CONTENTS
1.0 INTRODUCTION................................................................................ 4
2.0 SAFETY INFORMATION................................................................... 6
2.1
Follow Safety Instructions .................................................................. 7
2.2
Operating The Sprayer Safely ........................................................... 7
2.3 Handling Chemical Products Safely ............................................. 8
2.4 Local Poison Information Center .................................................. 9
3.0 HOOKING UP THE SPRAYER ....................................................... 10
4.0 OPERATING THE SPRAYER ......................................................... 11
4.1
Controls ........................................................................................... 11
4.2
ET Manual Control Operation .......................................................... 12
4.3 M600 Brass Manual Control Operation ........................................... 14
5.0 NOZZLE SELECTION ..................................................................... 16
5.1 Handgun Nozzle Selection ......................................................... 16
5.2 Boom Nozzle Selection .............................................................. 16
6.0 CALIBRATION ................................................................................ 18
6.1 Calibration (Ounce Method) ....................................................... 19
7.0 MAINTENANCE............................................................................... 19
7.1 Cleaning The Sprayer ................................................................ 19
7.2 Lubrication .................................................................................. 21
7.3 Nozzle Filters .............................................................................. 22
7.4 Nozzle Tubes and Fittings .......................................................... 22
7.5 Pump Maintenance .................................................................... 22
7.6 Boom Maintenance .................................................................... 23
8.0 STORAGE ....................................................................................... 24
8.1 Preparation After Storage ........................................................... 24
9.0 TROUBLESHOOTING..................................................................... 25
10.0 TECHNICAL SPECIFICATIONS ................................................... 26
10.1 HARDI
®
Diaphragm Pump Specifications ................................ 26
10.2 Sprayer Specifications .............................................................. 27
10.3 Safety Decals ........................................................................... 27
11.0 PARTS DRAWINGS ...................................................................... 28
12.0 WARRANTY POLICY AND CONDITIONS ................................... 41
13.0 NOTES ........................................................................................... 43
