Default setting
Text For HC 2500* For HM 1500**
[ Language ]GB GB
[ Unit ] Metric Metric
[ ON/OFF valve ] Present Present
[ Pressure system ] Equalisation Equalisation
[ Control box ] Connected Not Connected
[ Tank size ] 2000 l 2000 l
[ Analog adjustment ] max. 10 max. 10
min. 0 min. 0
offset in mA 0 mA offset in mA 0 mA
[ Analog unit text ] Bar Bar
[ Regulation con. ]0% 0%
[ Flow PPU ] 120.0 120.0
[ Speed UPP ] 1.0000 1.0000
HC 2500*
For EVC, ESC or CB control unit set:
[ ON/OFF valve ] to [ Not present ]
HM 1500**
For BK, BK/EC or EC control unit with switch (control) box for boom sections set:
[ Control box ] to [ Connected ]
For EVC, ESC or CB control unit set:
[ ON/OFF valve ] to [ Not present ]
[ Control box ] to [ Connected ]
NOTE: Re-start the system after leaving the Extended menu.
