29
Technical specifications
Supply voltage 12 Volt DC
Minimum supply 11 Volt DC
Maximum supply 16 Volt DC
Maximum peak 20 Volt DC
Ambient temperature – 10° C to + 55° C
Memory Flash PROM non-volatile
Digital transducers Square signal
Update frequency 4 times per second
Trigger high 5.0 to 12.0 Volt DC
Trigger low 0.0 to 0.5 Volt DC
Analog transducers
Supply Loop
Input 4 to 20 mA
Minimum speed for volume regulation 2.0 km/h
Flow ranges for the flow transducers
Identification code Orifice Flow
White 13.5 mm 5 to 150 l/min
Black 20.0 mm 10 to 300 l/min
One outside groove 13.5 mm 5 to 150 l/min
Two outside grooves 36.0 mm 35 to 600 l/min
Pressure drop over 13.5 mm orifice is 1 bar at 150 l/min.
Packaging information
Materials used for packaging are environmentally compatible.
They can be safely deposited or they can be burnt in an incinerator.
Recycling
Cardboard: Can recycle up to 99% and therefore should be put into
the waste collection system.
Polyethylene: Can be recycled.
When the HM 1500 / HC 2500 has completed its working life, it must
be thoroughly cleaned. The synthetic fittings can be incinerated.
The printed circuit boards and metallic parts can be scrapped.
