Hardi Navigator Series User Manual

43
HARDI NAVIGATOR
2 x 430286
2 x 430485
2 x 285668
4 x 63020704
4 x 460585
View from below
63020904
63020804
63012204
2 x 61008604
2 x 283699
2 x 460423
2 x 421002
63020604
2 x 430872
6 x 430721
63020504
2 x 22070304
14 x 460703
2 x 63012304
A
B
83307804 - 5000L ADJUST SUSPENSION
83308104 - 4000L ADJUST SUSPENSION
A
B
63012304
63012404
22070304
22070404
2 x 14701404
2 x 430286
8330xxxx - 3000L ADJUST SUSPENSION
63012404
XXXX
See Inset
6 x 430721
2 x 430522
4 x 460327
73010004
Lateral Control Rod
2 x 430264
2 x 33000204
61009004
2 x 460585
1.5 3m Adjustable Width / Suspension
Drg 19

Hardi Navigator Series Specifications

General

Tank Capacity	2400 to 6000 liters (depending on model)
Pump Type	diaphragm pump
Wheel Track Adjustment	Hydraulic or mechanical
Nozzle Spacing	50 cm
Weight	Varies depending on model and options; check specific model specifications
