No. A8a Enter the AT minimum temperature
No. A8b Enter the switch-on and switch-off times
No. A8c Enter flow set temperature
No. A9 Activation of screed heating function of the corresponding heat circuit
If On is selected, parameters A9a - A9f appear
A11: Second additional heat circuit on the control panel
A21, A31: When using an extension module 1
A41, A51: When using an extension module 2
A61: When using a heat circuit board A
Setting options: See heat circuit 1 (A1 - A9)
10.3 Parameter B - HWT
• No. B1 HWT 1 setting on available
Control of HWT 1
• HWT 1 setting on Loxone
Control of HWT 1 by the Loxone controller
• Parameter No. B1 on Not available
If No. B1 is set to Not available, Nos. B2 to B6 are not displayed.
Press on Name to name each HWT separately
No. B2 HWT 1 switch difference
Value at which the HWT is switched on below the set minimum temperature
Range: 1 - 40 °C
No. B3 Lower HWT limit temperature
If the HWT temperature drops below the preset value, HWT loading starts
within the set time (installer setting no. B90) regardless of the HWT time pro-
gramme (customer setting no. 1).
• Range: 1 - 80 °C
No. B4 Activate the Legionella protection programme
No. B5 HWT set temperature for legionella protection
Temperatures of 70 °C or above for more than 3 minutes will kill all legionella
in the HWT.
No. B6 Leg. prot. week prog.
Green = active
Start legionella protection during HWT loading only
HARGASSNER
Mo,25.11.18 08:19
AT minimum temperature
Default: 20 °C
No. A8a Heating circuit 1 Summer
heating
20°C
ON
No. A8b Heating circuit 1 Summer
heating
06:00
Off
Off
ON
09:00
18:00
21:00
HARGASSNER
Mo,25.11.18 08:19
Flow-target
Default: 30 °C
No. A8c Heating circuit 1 Summer
heating
30°C
HARGASSNER
Mo,25.11.18 08:19
Off
ON
No. A9 Heat circuit 1 Screed dry out
HARGASSNER
Mo,25.11.18 08:19
not available
Pump
Mixer
No. A11 Heat circuit 2
Loxone
Mixer Floor Heating
INSERT NAME
HARGASSNER
Mo,25.11.18 08:19
not available
No. B1 HWT 1
available
Loxone
INSERT NAME
HARGASSNER
Mo,25.11.18 08:19
HWT temperature differential
Default: 6 °C
No. B2 HWT 1
6°C
HARGASSNER
Mo,25.11.18 08:19
Minimum HWT temperature
Default: 40 °C
No. B3 HWT 1
40 °C
No. B4 Legionella prot. HWT 1
Off
ON
HARGASSNER
Mo,25.11.18 08:19
Legionella setpoint
Default: 70 °C
No. B5 Legionella prot. HWT 1
70 °C
HARGASSNER
Mo,25.11.18 08:19
No. B6 Leg. prot. week prog.
17:00
--:-- --:--
--:--
M Tu W Th F Sa Su
a.
b.
d.
c.
