7 Flue pipe - chimney connections
8 Electrical supply
 See according to enclosed electrical manual
• The electrical connection may only be established by a licensed and authorised
electrician and must be done in accordance with the enclosed electrical manual.
• Attach a lockable main power switch outside of the boiler room (depending on
building regulations).
• Max. prefuse 13 A (C characteristic)
• It is absolutely imperative that the intrinsically safe cables are permanently installed
• Use suitable mechanical components
• in-phase connection L and N (see electrical manual)
• Connect potential equalisation
• Use highly flexible cables (e.g. H05VV-F)
Description Unit Classic 12 Classic 14 Classic 15 Classic 22
Nominal heating output KW 12.0 14.9 15.0 22.0
Flue gas temperature °C 150 150 150 150
CO
2
% 14
Mass volume kg/Sec 0.0071 0.0082 0.0088 0.0129
Necessary pressure Pa 2
Flue draft max. limit Pa 10
Diameter of flue pipe connection mm 130
Water resistance dT 10° mbar 6.2 7.2 7.7 18.3
Water resistance dT 20° mbar 2.0 2.3 2.5 3.8
Electrical energy Characteristics Unit
Voltage 230 V ± 5 %
Frequency 50 Hz ± 5 %
Fuse 13 A
Power consumption 47 W
