Harley Benton DNAfx GiT - Connecting to Amplifier Input

AUX IN INPUT RIGHT USB OTGLEFT/MONO
PHONES
OUTPUT
9V 300MA
Amplier
Guitar
1. Connect the guitar to the input jack [INPUT] of the unit.
Turn o the [AMP] and [CAB] eects.
2. Connect the input of the amplier to the output jack [LEFT MONO] of the unit.
Connection to the input jack of
the amplier
Installation
16
DNAfx GiT
Multi Eects Unit
