Harley Benton DNAfx GiT - Connecting to an Effect Looper

AUX IN INPUT RIGHT USB OTGLEFT/MONO
PHONES
OUTPUT
9V 300MA
Amplier
Guitar
1. Connect the guitar to the input of an amplier.
2. Connect the SEND interface of the amplier to the input jack [INPUT] of the unit.
3. Connect the RETURN interface of the amplier to the output jack [LEFT MONO] of the
unit.
Connection to a eect looper
Installation
18
DNAfx GiT
Multi Eects Unit
