3 [VALUE] | Rotary control to change the menu pages and to change parameters.
4 [MASTER] | Rotary control to adjust the overall volume.
5 [FX], [DS], [AMP], [CAB], [NS], [EQ], [MOD], [DLY], [REV] | LED indicator light for eects
The active eect blocks in the eects chain for the currently set preset light up.
6 Expression pedal
7 [SYSTEM] | Button to call up the system settings
8 [TAP] | Button to call up the tab tempo settings
9 [RHYTHM] | Button to call up the conguration of Drums and Metronome
10
[LOOPER] | Footswitch to activate the looper
n Hold down the footswitch to activate the looper.
n With the looper activated: Press the footswitch to activate the STOP / CLEAR function.
11 [EXP] | Button to call up the conguration of the expression pedal
12 [SAVE] | Button to call up the preset memory menu
13 [PLAY] | Button to call up the preset menu screen
14
[TUNER] | Footswitch to activate the tuner
n Hold down the footswitch to activate the tuner.
n With the looper activated: Press the footswitch to activate the REC / PLAY / DUB function.
Connections and operating elements
