Harley-Davidson Dyna 2008 - Page 294

27
26
24
25
4
9
1
23
6
3
5
7
10
11
12
15
13
14
8
16
15
17
18
19
21
22
20
7
2
sm03719
19.10.1. Worm drive clamp, large (3)Retaining ring (2)Bolt, muffler-to-muffler
2. 20.11.Washer Cable clamp (2)Exhaust pipe flange
12.3. 21.Flange nut (4)Washer Muffler clamp (2)
22.13.4. Front (lower) mufflerFront oxygen sensorBolt, muffler mounting
5. 23.14.Muffler bracket Rear (upper) mufflerHead pipe assembly
15.6. 24.Worm drive clamp, small (4)Rear oxygen sensor Active exhaust cable
assembly16.7. Rear heat shieldFlange locknut (2)
25.8. Active exhaust module17.Bolt Front heat shield
18.9. 26.Collector heat shieldExhaust gasket (2) Washer
27. Active exhaust module
fastener
Figure 4-68. Exhaust System: FXDF
INSTALLATION: FXDF
NOTES
• See inset in Figure 4-68. Replacement exhaust gaskets
(9) are tapered internally. Be sure the thin end goes over
the exhaust pipe. Also check condition of retaining ring
(10) before installation.
• If mufflers were not removed, skip muffler installation
steps.
1. See Figure 4-68. If removed, install muffler bracket.
Tighten flange locknuts (7) to 15-19 ft-lbs (20.3-25.8 Nm).
Tighten bolt (8) to 15-19 ft-lbs (20.3-25.8 Nm).
2008 Dyna Service: Fuel System 4-35
