No. Button Name AVR Function DVD CD/CD-R Tape VCR (VID1) CBL (VID2) SAT (VID2) TV (VID3)
44 Direct Direct
Tuner Entry Angle Random Play FAV FAV
45 Clear Clear Clear Clear Clear Bypass Next Clear
46 Preset Up Preset Tune Up Slow Forward +10 Music Alt
47 Tuning Down Tune Down Prev Chapter Track Increment
48 OSD OSD Program OSD OSD OSD OSD
49 D.
Skip
Disc Skip
Disc Skip
50 Preset Down Preset Tune Down Slow Rev
51 M1 Macro 1
Macro 1 Macro 1 Macro 1 Macro 1 Macro 1 Macro 1 Macro 1
52 M2 Macro 2 Macro 2 Macro 2 Macro 2 Macro 2 Macro 2 Macro 2 Macro 2
53 M3 Macro 3 Macro 3 Macro 3 Macro 3 Macro 3 Macro 3 Macro 3 Macro 3
54 M4 Macro 4 Macro 4 Macro 4 Macro 4 Macro 4 Macro 4 Macro 4 Macro 4
55 Dolby Sur Dolby Modes
56 DTS Sur DTS Digital Modes
57 DTS Neo:6 DTS Neo:6 Select
58 Logic 7 Logic 7 Select
59 Stereo Stereo Mode Select
60 Skip Down Skip – (DVD) Skip – Skip – Scan – Skip – (DVD) Skip – (DVD) Skip – (DVD)
61 Skip Up Skip + (DVD) Skip + Skip + Scan + Skip + (DVD) Skip + (DVD) Skip + (DVD)
62 Rewind (‹‹) R. Search (DVD) R. Search R. Search Rewind Rewind R. Search (DVD) R. Search (DVD) R. Search (DVD)
63 Play (‹›) Play (DVD) Play Play R. Play/F. Play Play Play (DVD) Play (DVD) Play (DVD)
64 F F (››) F. Search (DVD) F. Search F. Search Fast Fwd Fast Fwd F. Search (DVD) F. Search (DVD) F. Search (DVD)
65 Record Record Record/Pause Record
66 Stop Stop (DVD) Stop Stop Stop Stop Stop (DVD) Stop (DVD) Stop (DVD)
67 Pause Pause (DVD) Pause Pause Pause Pause (DVD) Pause (DVD) Pause (DVD)
34 FUNCTION LIST
FUNCTION LIST
AVR 135 OM 12/3/04 12:11 PM Page 34

Harman Kardon AVR 135 Specifications

General

Type	AV Receiver
Number of Channels	5.1
Frequency Response	10Hz - 100kHz
Signal-to-Noise Ratio	95dB
Input Sensitivity	200mV
THD	0.07%
Surround Sound Formats	Dolby Digital, DTS
Tuner Presets	30
Input Impedance	47 kOhm
Input Digital Connectors	Coaxial, Optical
Dimensions	440 x 165 x 380 mm
Power Output	40W per channel
