9
Surround Mode
Tuning
Preset Stations
Surround Select
Tuner Band
Tuning Mode
Source Select
Headphone Jack
Digital Audio Inputs (Optical 3 and Coaxial 3)
Video 3 Video Inputs
Video 3 Analog Audio Inputs
Power Indicator
Main Power Switch
Standby/On Switch
Volume
Source Indicators
Message Display
Surround Mode Indicators
Speaker/Channel Input Indicators
NOTE: To make it easier to follow the instructions throughout the manual that refer to this illustration, a copy of this page may be downloaded from the Product Support section at
www.harmankardon.com.
