Pos Tocom# SName
0010 55260850 AC ESABD IAU KEY BD AVR1500
0020 20290150 SOLDER BAR 52SN/45PB/3SB BAR
0030 15481260 SLDC FLUX LRES FOAM SM32DHT-2
0040 20290240 SOLDER ALPHA RELIA. II 60/40 SOLDER WIRE 1.27 MM
CN401 55175800 WIRECONASY UNIQUE 8P 100MM UL1007 PVC DISCRETE 26 1
CN403 5515865A WIRECONASY UNIQUE 3P 390MM UL1007 PVC DISCRETE 26
CN405 55125040 CONN 2.0MM 12 MA R NAT MOLEX 35237-1210 0 0
CP403 55078520 CONN 2.0MM 2 MA R NAT LW2003P02 0 0
CP404 55123310 CONN 2.0MM 4 MA ST NAT LW2002P04 0 0
CP405 55124970 CONN 2.0MM 12 MA R NAT MOLEX 35336-1210 0 0
D401 55179330 D-LEM RED/GREEN 5 RD RND CL
HP601 55088400 CONN-PHJAC 6.35 ST HORZ EST-J6313 BK 0 0
R608 40440590 RMOF 330R0 OHM +5% 2.0W
R609 40440590 RMOF 330R0 OHM +5% 2.0W
W301 55158710 WIRECONASY UNIQUE 1P 150MM UL1007 PVC DISCRETE 22 1
Pos Tocom# SName
0010 55260910 AC ESABD SMD KEY BD AVR1500
J401 20441180 BCL 0.5MM TIN ANNEALED COPPER 10.0MM 8MM FIG 1 20322610
J402 20441240 BCL 0.5MM TIN ANNEALED COPPER 7.5MM 8MM FIG 1 20322610
J403 20441240 BCL 0.5MM TIN ANNEALED COPPER 7.5MM 8MM FIG 1 20322610
J404 20441240 BCL 0.5MM TIN ANNEALED COPPER 7.5MM 8MM FIG 1 20322610
J405 20441240 BCL 0.5MM TIN ANNEALED COPPER 7.5MM 8MM FIG 1 20322610
J407 20441180 BCL 0.5MM TIN ANNEALED COPPER 10.0MM 8MM FIG 1 20322610
SW401 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW402 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW403 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW404 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW405 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW406 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW407 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW408 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW409 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW410 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW411 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW412 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW413 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW414 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW415 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW416 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW417 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW418 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW419 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
SW420 55145270 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
PL DWG NO: 55260910
PL TITLE : AC ESABD SMD KEY BD AVR1500
PL TITLE : AC EMBD IMA KEY BD AVR1500
PL DWG NO: 55260850
PL DWG NO: 55260790
PL TITLE : AC ESABD IAU KEY BD AVR1500
