Harman Kardon AVR 1500

Pos Tocom# SName
0010 55260820 AC ESABD IAU MAIN BD AVR1500
0030 20290150 SOLDER BAR 52SN/45PB/3SB BAR
0040 15481260 SLDC FLUX LRES FOAM SM32DHT-2
0050 20290240 SOLDER ALPHA RELIA. II 60/40 SOLDER WIRE 1.27 MM
0060 55130170 AC METAL HEATSINK REG TR RT2280 2P --
0070 55298430 AC METAL HEATSINK REG TR 3P --
0071 55311150 AC METAL HEATSINK DIODE --
0072 55127070 SCREW-ST 3MM 10MM JIS B 1122 25 0 0
0080 55127070 SCREW-ST 3MM 10MM JIS B 1122 25 0 0
C120 55183340 CE 8MI2F +20% 80.0V 85C
C121 55183340 CE 8MI2F +20% 80.0V 85C
C127 40433130 CE 2MI2F +20% 35.0V 85C
C128 40433130 CE 2MI2F +20% 35.0V 85C
C138 55126160 CE 6MI8F +20% 16.0V 85C
C139 55126160 CE 6MI8F +20% 16.0V 85C
C461 55129660 CPM 680N0F +10% 63.0V
CN116 55125040 CONN 2.0MM 12 MA R NAT MOLEX 35237-1210 0 0
CN201 55158630 WIRECONASY UNIQUE 3P 80MM UL1007 PVC DISCRETE 26
CN300 55285970 WIRECONASY UNIQUE 12P 190MM UL1007 PVC DISCRETE 26 1
CN400 55177600 CONN 2.5MM 10 MA ST NAT 0 0
CN501 55144670 WIRECONASY UNIQUE 7P 90MM UL1007 PVC DISCRETE 22 1
CN502 55184150 WIRECONASY UNIQUE 10P 80MM UL1007 PVC DISCRETE 26
CP116 55124970 CONN 2.0MM 12 MA R NAT MOLEX 35336-1210 0 0
CP121 55177620 CONN 2.5MM 3 MA ST NAT 0 0
CP201 55090080 CONN 2.0MM 3 MA ST NAT LW2002P03 0 0
CP301 55192770 CONN 1.25MM 29 FE ST BK 00-8370-291-000-800 2794 A6
CP304 55090050 CONN 2.0MM 10 MA ST NAT LW2002P10 0 0
CP401 55124990 CONN 2.0MM 14 MA R NAT MOLEX 35336-1410 0 0
CP402 55124960 CONN 2.0MM 11 MA R NAT MOLEX 35336-1110 0 0
CP503 55146590 CONN 2.5MM 5 MA ST NAT 0 0
D112 55134080 D-BRDLC RS603M
D113 20415060 D-SR 1N4004 400.0V 1.0A
D114 20415060 D-SR 1N4004 400.0V 1.0A
D115 20415060 D-SR 1N4004 400.0V 1.0A
D116 20415060 D-SR 1N4004 400.0V 1.0A
D118 20415060 D-SR 1N4004 400.0V 1.0A
D119 20415060 D-SR 1N4004 400.0V 1.0A
D120 20415060 D-SR 1N4004 400.0V 1.0A
D121 20415060 D-SR 1N4004 400.0V 1.0A
D900 20525530 D-SR 1N4003 200.0V 1A
G100 55135980 TERMLUG GND
IC102 20832440 IC-REGPOSFXD KIA7815API NORMAL
IC103 55124020 IC-REGNEGFXD KIA7915PI NORMAL
IC104 55123960 IC-REGPOSFXD KIA7805API NORMAL
IC105 55123990 IC-REGNEGFXD KIA7905PI NORMAL
IC106 55125450 IC-REGPOSFXD BA033T NORMAL
IC200 20832580 IC-SWITCH LC78211 ANALOG SWITCH
IC201 20832580 IC-SWITCH LC78211 ANALOG SWITCH
JK100 55262230 CON PHONO SCKT RCA 2P
JK104 55262240 CONN-SPE TERMINAL SPKR 6P -- FE 4.5MM 6 GN 0 0
JK105 55191390 CONN-SPE TERMINAL SPKR 4P SH0410376P FE 19MM 4 BK 0 0
JK106 55176330 CON PHONO SCKT RCA 4P JW4104RS GND
JK107 55176330 CON PHONO SCKT RCA 4P JW4104RS GND
JK109 55088230 CON PHONO SCKT RCA-606P 6 PINS
JK111 55191370 CON PHONO SCKT RCA 1P JACK JE010003XN
JK112 55149520 CON DIN SCKT MIX SOCKET RCA-118JP1S
PL TITLE : AC EMBD IMA MAIN BD AVR1500
PL DWG NO: 55260760
