Harman Kardon AVR 1500 - Page 7

D230 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D231 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D231 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D233 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D233 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D234 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D234 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D235 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D235 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D236 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D236 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D237 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D237 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D238 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D238 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D239 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D239 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D240 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D240 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D241 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D241 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D244 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D244 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D245 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D245 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D246 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D246 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D247 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D247 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D266 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D266 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D267 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D267 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D268 55179290 D-LEM LTL-1CHGEC P-GN RND CL
D268 55199400 D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
FINGER 55178960 AC SPRING PLATE SPRING GND C5212 0.2T AVR520
FL201 55155740 DISPLAY HNA-10MM22
IC201 55336450 IC-MICROCONT CXP82860-355Q AVR1500
JA201 55113740 CON PHONO SCKT RCA-307 3 PINS
JA202 55113960 CON DIN SCKT SOCKET CONNECTOR SVHS EST-S408J
L201 55179380 LF 4U7H +10% 1.7 OHM 190.0A
L202 55179380 LF 4U7H +10% 1.7 OHM 190.0A
RM201 55155930 IC-REMOTE RPM6938-RSIP-A3 RECEIVER 38KHZ
VR201 55134900 SWIROT EC16B24204A5 5V 500U0A 10T 3P 0 0
W301 55158710 WIRECONASY UNIQUE 1P 150MM UL1007 PVC DISCRETE 22 1
W401 55158710 WIRECONASY UNIQUE 1P 150MM UL1007 PVC DISCRETE 22 1
X201 55126140 CRESONATOR 10M0 HZ 25.0 OHM 0F
Pos Tocom# SName
0010 55260870 AC ESABD SMD FRONT BD AVR1500
C1 20267830 CE 47U0F +20% 16.0V 85C
C202 20267830 CE 47U0F +20% 16.0V 85C
C203 20267830 CE 47U0F +20% 16.0V 85C
C204 20269010 CE 47U0F +20% 50.0V 85C
C210 20268880 CE 10U0F +20% 50.0V 85C
C214 20267830 CE 47U0F +20% 16.0V 85C
C215 20267830 CE 47U0F +20% 16.0V 85C
C219 20269010 CE 47U0F +20% 50.0V 85C
C220 20268880 CE 10U0F +20% 50.0V 85C
C234 20268950 CE 100N0F +20% 50.0V 85C
PL DWG NO: 55260810
PL TITLE : AC ESABD IAU FRONT BD AVR1500
