31
AVR 158
ENGLISH
Appendix
Surround Mode
Description
Incoming Bitstream or Signal
DTS Digital Using a different encoding/decoding method from Dolby Digital, DTS Digital
also provides up to five discrete main channels, plus an LFE channel.
DTS 1/0/.0 or .1, 2/0/.0 or .1, 3/0/.0 or .1, 3/1/.0 or •
.1, 2/2/.0 or .1, 3/2/.0 or .1
DTS-ES Matrix (played as 5.1) •
DTS-ES Discrete (played as 5.1) •
DTS-HD
DTS-HD is a high-definition audio format that complements the high-definition video
found on Blu-ray Disc and HD-DVD discs. It is transmitted using a DTS core with
high-resolution extensions. Even when only DTS 5.1 surround sound is desired (or
available, if the multizone system is in use), the higher capacity of high-resolution
discs serves up DTS at twice the bit rate used on DVD-Video discs.
Blu-ray Disc or HD-DVD discs encoded with DTS-HD modes, •
delivered via HDMI connection
DTS-HD Master Audio
DTS-HD Master Audio technology delivers bit-for-bit reproductions of studio master
recordings for an incredibly accurate performance.
Blu-ray Disc or HD-DVD discs encoded with DTS-HD Master •
Audio technology, delivered via HDMI connection
DTS Stereo
Delivers a two-channel downmix of DTS Digital materials or presents a matrix-
encoded surround presentation.
DTS 1/0/.0 or .1, 2/0/.0 or .1, 3/0/.0 or .1, 3/1/.0 •
or .1, 2/2/.0 or .1, 3/2/.0 or .1
DTS 96/24 •
DTS-ES Matrix •
Logic 7
Mode Group
A HARMAN proprietary technology, Logic 7 technology enhances two-channel
and matrix-encoded recordings by deriving separate information for the surround
back channels. It provides more accurate placement of sound, improves panning
and expands the sound field, even when used with 5.1-channel systems. Logic 7
technology uses 96kHz processing and is available in 5.1 mode. Three variants are
available.
See below
Logic 7
Movie
Especially suited to two-channel sources containing Dolby Surround or matrix
encoding, Logic 7 Movie mode increases centre-channel intelligibility.
Analogue (two-channel) •
Tuner •
PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •
Logic 7
Music
The AVR is programmed at the factory to default to this mode for two-
channel signals. Logic 7 Music mode is well suited to conventional two-
channel music recordings.
Analogue (two-channel) •
Tuner •
PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •
Logic 7
Game
Use Logic 7 Game mode to enhance enjoyment of video-game consoles.
Analogue (two-channel) •
Tuner •
PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •
5-Channel Stereo
Useful for parties, the left- and right-channel information is played through both
the front and surround speakers on each side, while the centre speaker plays a
summed mono mix.
Analogue (two-channel) •
Tuner •
PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •
2-Channel Stereo
Turns off all surround processing and plays a pure two-channel signal or a
downmix of a multichannel signal. The signal is digitised and bass management
settings are applied, making it appropriate when a subwoofer is used.
Analogue (two-channel; DSP downmix available for multichannel) •
Tuner •
PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •
Table A9 – Surround Modes (cont.)
0296CSK - HK (x65Series) AVR158-230 OM [HKP1992], WORK05.indd 31 30/06/11 14:00:06
