Harman Kardon AVR 160 Service Manual

Level Ref. # Part Number
Description
Drawin
g
No
(
Value
)
Qt
y
..3 CTB3+8JFZR SCREW 12
..3 CTS3+8JFZR SCREW 4
..3 CTW3+12JR SCREW 2
..3 CUA1A294 CHASSIS , BOTTOM 1
..3 KHR1A028 BUSHING , AC CORD 1
..3 BN90 CSH1A009ZVB SWITCH , MOMS WIRE ASS'Y (2P, 80MM, RED) 1
...4 CSH1A009ZV SWITCH , MOMS 1
...4 CWB4F202080UK WIRE ASS'Y (3.96MM, 80MM, 2P, RED) 1
..3 CB12 CWC4C4A27B100B10 CARD , CABLE (27p,1.25mm Pitch,100mm Length,Protec 1
..3 CB14 CWC4C4A15B080B10 CABLE , CARD (15P,1.25MM,80MM,B,10MM) 1
..3 CB15 CWC4F2A17A100B10 CARD , CABLE (17P,1.0mm Pitch,100mm Length,Protect 1
..3 F901 KBA2C4000TLEY FUSE(218 Series, 250V, 4A) 4A/250V(EUR) 1
..3 T901 CLT5V052ZW TRANS , POWER (AC240V/50Hz) 1
Level
Ref. # Part Number
Description
Drawin
g
No
(
Value
)
Qt
y
..3 COP12168E AVR160 FRONT PCB ASS'
Y
1
....5 C121 CCBS1H151KBT CAP , CERAMIC(150PF/50V) CH UP025 B151K-A-B Z 1
....5 C122 CCEA1AH331T CAP , ELECT 330UF 10V 1
....5 C151 CCBS1H473ZFT CAP , CERAMIC(47000PF/50V) CH UP025 F473Z-A-B J 1
....5 C152 CCEA1CKS100T CAP , ELECT 10UF 16V 1
....5 C161 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1
....5 C213 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1
....5 C214 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1
....5 C252 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V SMALL SIZE 1
....5 C311 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) CH UP025 B102K-A-B Z 1
....5 C322 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) CH UP025 B102K-A-B Z 1
....5 C412 CCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z 1
....5 C413 CCEA1JH470TS CAP , ELECT 63V/47UF/105'C 1
....5 C414 CCEA1JH470TS CAP , ELECT 63V/47UF/105'C 1
....5 C415 CCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z 1
....5 C422 CCEA1HH4R7T CAP , ELECT 4.7UF 50V 1
....5 C431 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1
....5 C441 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1
....5 C442 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1
....5 C503 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1
....5 C504 CCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z 1
....5 C511 CCBS1H560JT CAP , CERAMIC(56PF/50V) CH UP025SL560J-A-B Z 1
....5 C512 CCBS1H560JT CAP , CERAMIC(56PF/50V) CH UP025SL560J-A-B Z 1
....5 C521 CCEA1AH101T CAP , ELECT 100UF 10V 1
....5 C522 CCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z 1
....5 C531 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1
....5 C533 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1
....5 C541 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z 1
....5 C542 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C553 CCBS1H471KBT CAP , CERAMIC(470PF/50V) CH UP025 B471K-A-B Z 1
....5 C554 CCBS1H471KBT CAP , CERAMIC(470PF/50V) CH UP025 B471K-A-B Z 1
....5 C601 CCBS1H181KBT CAP , CERAMIC(180PF/50V) CH UP025 B181K-A-B Z 1
....5 C602 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1
....5 C603 CCBS1H100JCT CAP , CERAMIC(10PF/50V) CH UP025CH100J-A-B Z 1
....5 C611 CCEA1AH471T CAP , ELECT 470UF 10V 1
....5 C612 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1
....5 C631 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1
....5 C633 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1
....5 C651 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1
....5 C652 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1
....5 C653 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1
....5 C714 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1
....5 C715 CCEA1CKS100T CAP , ELECT 10UF 16V 1
....5 C721 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V SMALL SIZE 1
....5 C731 CCEA1AH471T CAP , ELECT 470UF 10V 1
....5 C732 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1
....5 C751 CCBS1C222MXT CAP , CERAMIC(2200PF/16V) CH EP025 B222M-A-B J 1
....5 C752 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) CH UP025 B102K-A-B Z 1
....5 C753 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) CH UP025 B102K-A-B Z 1
....5 C754 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1
....5 C801 CCEA1EH470T CAP , ELECT 47UF 25V 1
....5 C802 CCEA1EH470T CAP , ELECT 47UF 25V 1
....5 C811 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C813 CCBS1H470JT CAP , CERAMIC(47PF/50V) CH UP025SL470J-A-B Z 1
....5 C821 CCBS1H471KBT CAP , CERAMIC(470PF/50V) CH UP025 B471K-A-B Z 1
....5 C822 CCBS1H151KBT CAP , CERAMIC(150PF/50V) CH UP025 B151K-A-B Z 1
....5 C823 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C830 CCBS1H473ZFT CAP , CERAMIC(47000PF/50V) CH UP025 F473Z-A-B J 1
....5 C901 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C902 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C911 CCEA1EH470T CAP , ELECT 47UF 25V 1
....5 C912 CCEA1EH470T CAP , ELECT 47UF 25
V
1
BOTTOM CHASSIS ASS'
Y
FRONT PCB ASS
Y
harman/kardon
AVR 160/230 Service Manual
14 of 116

Harman Kardon AVR 160 Specifications

General

Receiver type	Surround
RMS rated power	35 W
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
Power output per channel (1KHz@6 Ohm)	110 W
Digital audio coaxial out	1
Digital audio optical in	3
Connectivity technology	Wired
Speakers connectivity type	-
Ethernet LAN	No
Supported radio bands	AM, FM
Preset stations quantity	30
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Apple docking compatibility	Not supported

Weight and Dimensions

Depth	382 mm
Width	440 mm
Height	165 mm
Weight	10500 g
