Harman Kardon AVR 160 Service Manual

Level Ref. # Part Number
Description
Drawin
g
No
(
Value
)
Qt
y
0,2 CGB1A217Z BADGE , AVR160 1
0,2 CGL1A222 INDICATOR , VOLUME AVR130/230/330 1
0,2 CGR3A436 COVER , JACK A 1
0,2 CGR3A437 COVER , JACK B 1
0,2 CGU1A318Y ORNAMENT , VOLUME AVR255 1
0,2 CGU1A410A25N WINDOW , FIP 1
0,2 CGX1A338MBC63 CAP , VOLUME 1
0,2 CGX1A391C66 ORNAMENT , AL A AVR350 1
0,2 CGX1A392C66 ORNAMENT , AL B AVR350 1
0,2 CGX2A390C66T SHEET , AL FRONT 1
0,2 CKC6B145S60 CABINET , TOP AVR350 1
0,2 CMH1A214 HOLDER , VOLUME AVR130/230/330 1
0,2 CMZ2A090 SHEET , VOLUME 1
0,2 CQB1A549Y LABEL , ATTENTION DVD48 1
0,2 CQB1A622 LABEL , SERIAL NO 1
0,2 CTB3+8JFZR SCREW 17
0,2 CTB4+6FFZR SCREW 6
1 CHE154 CLAMPER , ARM 0,12
1 CJXAVR340MICRO MICRO PHONE ASS'Y 1
1 CPG1A891W BOX , OUT CARTON 1
1 CPS5A564Z PAD , SNOW L AVR155 1
1 CPS5A565Z PAD , SNOW R AVR155 1
1 CQB1A907Z LABEL , BAR CODE AVR154 1
1 CQB1A928Z LABEL , MADE IN PRC 2
1 CQS1A001 RIBON , BAR CODE SONY(TR-4070) 0,12
1 CQXAVR160/240 INSTRUCTION MANUAL ASS'Y 1
0,2 CARTAVR160E-HK REMOCON ASS'Y (66KEY) AVR160 1
0,2 CQB1A971 LABEL , BAR CODE(MANUAL) 1
0,2 CQE1A220Z SHEET , FRONT COVER AVR130/230BK 1
0,2 CQE1A411Z SHEET , BATTERY HARMAN 1
0,2 CQX1A1432Z MANUAL , INSTRUCTION 1
0,2 CSA1A018Z FM 1 POLE ANT 1
0,2 CSA1A032Z ANT , AM LOOP 1
Level
Ref. # Part Number
Description
Drawin
g
No
(
Value
)
Qt
y
0,2 CGWAVR160/24
0
FRONT PANEL ASS'
Y
1
..3 CBT2A1064 KNOB , STANDBY 1
..3 CBT2A1065 KNOB , BACK 1
..3 CGB1A158Y BADGE , FRONT HARMAN/KARDON 1
..3 CGL1A265Y INDICATOR , POWER AVR155 1
..3 CGW3A447RHZB24 PANEL , FRONT 1
..3 CHG1A309 RUBBER 1
..3 CHR301 CLAMPER 6
..3 CMC1A372 PLATE , SHIELD 2
..3 CMC2A323 PLATE , SHIELD 1
..3 CMC2A326 PLATE , EARTH AVR350 3
..3 CMC2A338 PLATE , EARTH AVR350 2
..3 CMD1A555 BRACKET , SIDE (L) 1
..3 CMD2A443 BRACKET , SIDE 1
..3 CMH1A297 HOLDER , USB 1
..3 CMH2A215 HOLDER , LED AVR350 1
..3 CMZ1A127 FILTER , FIP AVR255 1
..3 CPE1A009 SHEET , BLIND 1
..3 CTB3+8JFZR SCREW 28
..3 CTWS3+10GR SCREW 1
..3 CB72 CWC4C4A31B250B08 CARD , CABLE (31p,1.25mm,250mm,08mm) 1
Level
Ref. # Part Number
Description
Drawin
g
No
(
Value
)
Qt
y
0,2 CUAAVR160/24
0
BOTTOM CHASSIS ASS'
Y
1
..3 CHD1A012ZR SCREW , SPECIAL 2
..3 CHD1A023R SCREW , SPECIAL 4
..3 CHD4A012R SCREW , SPECIAL 5
..3 CHE170 HOLDER , PCB 2
..3 CHE36-3 CLAMPER , WIRE 1
..3 CHG1A113 RUBBER 3
..3 CHG1A160Z CUSHION , RUBBER 1
..3 CHG1A373 CUSHION , FOOT AVR350 4
..3 CHS1A032 TAPE , HEMELON 4
..3 CJA2B043ZA CORD , POWER(EUR) QDR-7100CC 1
..3 CKF4A398Z PANEL , REAR 1
..3 CKL1A094 FOOT , A AVR350 2
..3 CKL1A095 FOOT , B AVR350 2
..3 CTB3+10JFZR SCREW 18
..3 CTB3+6FFZR SCREW 8
AVR160/230 Electrical & Mechanical Parts List
FRONT PANEL ASS
Y
BOTTOM CHASSIS ASS'
Y
harman/kardon
AVR 160/230 Service Manual
13 of 116

Harman Kardon AVR 160 Specifications

General

Receiver type	Surround
RMS rated power	35 W
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
Power output per channel (1KHz@6 Ohm)	110 W
Digital audio coaxial out	1
Digital audio optical in	3
Connectivity technology	Wired
Speakers connectivity type	-
Ethernet LAN	No
Supported radio bands	AM, FM
Preset stations quantity	30
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Apple docking compatibility	Not supported

Weight and Dimensions

Depth	382 mm
Width	440 mm
Height	165 mm
Weight	10500 g
