Harman Kardon AVR 160 Service Manual

Level Ref. # Part Number
Description
Drawin
g
No
(
Value
)
Qt
y
....5 Q942 HVTKTC3199YT T.R KTC3199Y 1
....5 Q943 HVTKTC3199YT T.R KTC3199Y 1
....5 Q960 HVTKRC107MT T.R KRC107M 1
....5 Q961 HVTKTA1024YT T.R 1
....5 R500 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
....5 R501 CRD20TJ433T RES , CARBON 43K OHM 1/5W J 1
....5 R502 CRD20TJ433T RES , CARBON 43K OHM 1/5W J 1
....5 R503 CRD20TJ433T RES , CARBON 43K OHM 1/5W J 1
....5 R504 CRD20TJ433T RES , CARBON 43K OHM 1/5W J 1
....5 R505 CRD20TJ433T RES , CARBON 43K OHM 1/5W J 1
....5 R506 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1
....5 R507 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1
....5 R508 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1
....5 R509 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1
....5 R510 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1
....5 R511 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1
....5 R512 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1
....5 R513 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1
....5 R514 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1
....5 R515 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1
....5 R516 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1
....5 R517 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1
....5 R518 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1
....5 R519 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1
....5 R520 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1
....5 R521 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1
....5 R522 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1
....5 R523 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1
....5 R524 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1
....5 R525 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1
....5 R531 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
....5 R532 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
....5 R533 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
....5 R534 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
....5 R535 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
....5 R536 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
....5 R537 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
....5 R538 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
....5 R539 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
....5 R540 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
....5 R541 CRD20TJ271T RES , CARBON 270 OHM 1/5W J 1
....5 R542 CRD20TJ271T RES , CARBON 270 OHM 1/5W J 1
....5 R543 CRD20TJ271T RES , CARBON 270 OHM 1/5W J 1
....5 R544 CRD20TJ271T RES , CARBON 270 OHM 1/5W J 1
....5 R545 CRD20TJ271T RES , CARBON 270 OHM 1/5W J 1
....5 R556 CRD20TJ273T RES , CARBON 27K OHM 1/5W J 1
....5 R557 CRD20TJ273T RES , CARBON 27K OHM 1/5W J 1
....5 R558 CRD20TJ273T RES , CARBON 27K OHM 1/5W J 1
....5 R559 CRD20TJ273T RES , CARBON 27K OHM 1/5W J 1
....5 R560 CRD20TJ273T RES , CARBON 27K OHM 1/5W J 1
....5 R561 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J 1
....5 R562 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J 1
....5 R563 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J 1
....5 R564 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J 1
....5 R565 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J 1
....5 R566 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R567 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R568 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R569 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R570 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R571 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R572 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R573 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R574 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R575 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R576 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1
....5 R577 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1
....5 R578 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1
....5 R579 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1
....5 R580 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1
....5 R581 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R582 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R583 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R584 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R585 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R586 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R587 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R588 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
....5 R589 CRD20TJ561
T
RES , CARBON 560 OHM 1/5W J 1
MAIN PCB ASS
Y
harman/kardon
AVR 160/230 Service Manual
20 of 116

Harman Kardon AVR 160 Specifications

General

Receiver type	Surround
RMS rated power	35 W
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
Power output per channel (1KHz@6 Ohm)	110 W
Digital audio coaxial out	1
Digital audio optical in	3
Connectivity technology	Wired
Speakers connectivity type	-
Ethernet LAN	No
Supported radio bands	AM, FM
Preset stations quantity	30
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Apple docking compatibility	Not supported

Weight and Dimensions

Depth	382 mm
Width	440 mm
Height	165 mm
Weight	10500 g
