FUNCTION LIST
FUNCTION LIST 37
No. Button Name AVR Function DVD CD/CD-R Tape VCR (VID1) TV (VID2) CBL (VID3) SAT (VID3)
45 Tune Up Tune Up Next Chapter Track Direct Cancel Sleep
46 Direct Direct Tuner Entry Angle Random Play FAV FAV
47 Clear Clear Clear Clear Clear Clear Bypass Next
48 Preset Up Preset Tune Up Slow Forward +10 Music Alt
49 Tune Down Tune Down Prev Chapter Track Increment
50 OSD OSD Program OSD OSD OSD OSD
51 D. Skip Disc Skip Disc Skip
52 Preset Down Preset Tune Down Slow Rev
53 M1 Macro 1
54 M2 Macro 2
55 M3 Macro 3
56 M4 Macro 4
57 Dolby Dolby Modes
58 DTS Surr DTS Digital Modes
59 DTS Neo:6 DTS Neo:6 Select
60 Logic 7 Logic 7 Select
61 Stereo Stereo Mode Select
62 Skip Down Skip – Skip – Scan –
63 Skip Up Skip + Skip + Scan +
64 Rewind R. Search R. Search Rewind Rewind
65 Play Play Play Play Play
66 Fast Forward F. Search F. Search Fast Fwd Fast Fwd Day + Day +
67 Record Record Record Record
68 Stop Stop Stop Stop Stop
69 Pause Pause Pause Pause

Harman Kardon AVR 230 Specifications

General

Dolby Digital	Yes
DTS	Yes
Input Sensitivity	200mV
Signal-to-Noise Ratio	100dB
Impedance	8 ohms
Type	AV Receiver
Input Impedance	47k ohms
Total Harmonic Distortion	0.07%
Surround Sound Formats	Dolby Digital, DTS, Dolby Pro Logic II
Digital outputs	1 optical
Width	440mm
Height	165mm
Power Output per Channel	50W
Frequency Response	10Hz – 100kHz
Audio D/A Converter	24-bit/192kHz
Digital inputs	3 Optical, 3 Coaxial
Video Inputs	4 Composite
Video Outputs	1 Composite, 1 S-Video
Audio Inputs	6 x RCA
Depth	376mm
Audio Outputs	1 Analog
