Harman Kardon AVR 3500 Service Manual

AVR 2500 AVR 3500 AVR 4500 AVR 5500
Remote Control 55242980 55242990 55262320/55178550 55262330/55178550
Power Transformer 230V 55201720 55201720 55274640 55163910
St-By Transformer 230V 55155650 55155650 55155650 55155650
Carton Box 55243010XX 55243020XX 5524300XX 5524310XX
Micro controller Main IC201 55267250 55267250 55285950 55285950
Micro controller SUB IC128 55285930 55285930
Key SW PCB asm 55243610 55245880 55315730 55315700
Front PCB asm 55246230 55245850 55261830 55261820
Main PCB asm 55246120 55245840 55261860 55261840
Video PCB asm 55243640 55245890 55261900 55261890
DSP PCB asm 55243670 55245900 55261880 55261870
Processor PCB asm 55243540 55245860 55196680 55182700
Tuner PCB asm 5522774A 5522774A 55317330 55317330
Surround PCB asm 55271240 55245870 55261930 55261940
Component PCB asm
Input PCB asm 55261920 55261910

Harman Kardon AVR 3500 Specifications

Power

continuous average power (stereo mode)	55 watts per channel into 8 ohms
continuous average power (five-channel surround mode)	45 watts per channel into 8 ohms
high instantaneous current capability (HCC)	±28 amps

Tuner Specifications

usable sensitivity	IHF 1.3µV/13.2dBf
THD at 1kHz with 100% modulation (mono)	0.2%
THD at 1kHz with 100% modulation (stereo)	0.3%

Weight and Dimensions

dimensions (H x W x D)	165mm x 440mm x 435mm
weight	14kg
