Harman Kardon AVR 3500 Service Manual

PART NO
:55245900
TITEL
: AC EMBD IMA DSP BD AVR3500
Pos
Tocom#
Pkg
M/B
St
Qty
Unit
SName
010
55245970
M
SO
1
PCE
AC ESABD IAU DSP BD AVR3500
030
20290150
B
so
0.3
KG
SOLDER BAR 52SN/45PB/3SB BAR
031
55148120
B
ud
0.3
PCE
AC ART SILKSCREEN CDRW1211
032
20290240
B
so
0.005
KG
SOLDER ALPHA RELIA. II 60/40 SOLDER WIRE 1.27 MM
050
55182550
B
ud
1
PCE
AC PUN SHIELD DIGITAL ET
C112
20252560
30
B
so
1
PCE
CE 220U0F +20% 6.3V 85C
C148
20269180
AM
B
so
1
PCE
CE 1MI0F +20% 6.3V 85C
C149
20269180
AM
B
so
1
PCE
CE 1MI0F +20% 6.3V 85C
C150
20269180
AM
B
so
1
PCE
CE 1MI0F +20% 6.3V 85C
CN05
55175860
NR
B
so
1
PCE
WIRECONASY UNIQUE 5P 480MM UL1007 PVC DISCRETE 26 1
COIL1
55176540
NR
B
so
1
PCE
TFPULSE TRANSFORMER 110UH FP-110 FERRIT MAGNET
CP01
55124690
B
so
1
PCE
CONN 1.25MM 21 FE R WH GF120-21S-LS 2794 A6
CP02
55125030
B
so
1
PCE
CONN 2.0MM 11 MA R NAT MOLEX 35237-1110 0 0
CP03
55174650
B
so
1
PCE
CONN 2.0MM 16 MA R NAT SOCKET MOLEX 35237-1610 0 0
CP04
55123390
B
so
1
PCE
CONN 2.0MM 5 MA R NAT LW2003P05 0 0
JAC1
55125430
NR
B
so
1
PCE
D-LEM TORX178B RD RND CL
JAC2
55125430
NR
B
so
1
PCE
D-LEM TORX178B RD RND CL
JAC3
55191600
B
so
1
PCE
CON PHONO SCKT RCA 2P W/GNDCAP JW-1502SN OO
JAC4
55125440
NR
B
so
1
PCE
D-LEM TOTX178B RD RND CL
JAC5
55175950
B
so
1
PCE
CON PHONO SCKT RCA 1P W/GND JE010003MN
JAC6
55125430
NR
B
so
1
PCE
D-LEM TORX178B RD RND CL
JAC7
55175240
B
so
1
PCE
CON PHONO SCKT RCA 1P W/GND JE010003MG
OSC1
55126130
NR
B
so
1
PCE
VCXO 12M288 HZ +50 PPM -50 PPM 0 OHM
W001
55180120
NR
M
SO
1
PCE
WIRECONASY UNIQUE 1P 100MM UL1007 PVC DISCRETE 18 1
PART N
O : 55245970
TITEL
: AC ESABD IAU DSP BD AVR3500
Pos
Tocom#
Pkg
M/B
St
Qty
Unit
SName
022
5524476D
B
so
1
PCE
AC PCB DSP BD 144*184XT AVR120US -
C020
55179400
71
B
so
1
PCE
CPM 68N0F +5% 63.0V
C031
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C032
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C056
20268850
30
B
so
1
PCE
CE 2U2F +20% 50.0V 85C
C068
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C069
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C070
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C071
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C080
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C081
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C082
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C083
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C092
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C093
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C094
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C095
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C110
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C111
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C114
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C115
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C116
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C117
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C118
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C119
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C146
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C

Harman Kardon AVR 3500 Specifications

Power

continuous average power (stereo mode)	55 watts per channel into 8 ohms
continuous average power (five-channel surround mode)	45 watts per channel into 8 ohms
high instantaneous current capability (HCC)	±28 amps

Tuner Specifications

usable sensitivity	IHF 1.3µV/13.2dBf
THD at 1kHz with 100% modulation (mono)	0.2%
THD at 1kHz with 100% modulation (stereo)	0.3%

Weight and Dimensions

dimensions (H x W x D)	165mm x 440mm x 435mm
weight	14kg
