Table A2 – Source Setting Defaults
Cable/Sat DVD Media Server Radio TV Game AUX The Bridge
Surround Modes (Auto Select) Logic 7 Movie Logic 7 Movie Logic 7 Movie Logic 7 Movie Logic 7 Movie Logic 7 Movie Logic 7 Movie Logic 7 Movie
Video Input HDMI 2 HDMI 1 S-Video 1 N/A
Component 1 Composite 1 Composite Front The Bridge II
Audio Input HDMI 2 HDMI 1 Optical 2 N/A Optical 1 Coaxial 1 Coaxial Front
The Bridge II
Resolution to Display 480i 480i 480i 480i 480i 480i 480i 480i
Audio Auto Polling Analog 1 Analog 2 Analog 5 N/A Analog 3 Analog 4 Analog Front
The Bridge II
Zone 2 Audio Analog 1 Analog 2 Analog 5 N/A Analog 3 Analog 4 Analog Front
The Bridge II
59
APPENDIX
Appendix – Default settings, worksheets, remote product codes
Table A1 – Recommended Source Component Connections
Device Type AVR 354 Source Digital Audio Connection Analog Audio Connection Video Connections
Cable TV, satellite TV, HDTV CBL/SAT HDMI 2 Analog 1 HDMI 2
or other device that delivers
television programs
DVD Audio/Video, SACD, DVD HDMI 1 Analog 2 HDMI 1
Blu-ray Disc, HD-DVD player
Media Server, including Media Server Optical 2 Analog 5 S-Video 1
Harman Kardon DMC 1000
TV TV Optical 1 Analog 3 Component 1
*
Video game console Game Coaxial 1 Analog 4 Composite 1
Any audio or video device, AUX Coax Front Analog Front Composite Front (not used for
e.g., CD player, camcorder, audio-only devices)
cassette deck
Recorder Any Coaxial 1 or 2 input and Analog 4 inputs and outputs Composite OR S-Video 2 input
Coaxial Output and output
iPod The Bridge II None The Bridge II The Bridge II for photo- and video-
capable iPod models
*
Make this connection only when using the TV source for a non-display device. Do not connect your television’s or video display’s video output to the AVR at any time.
