Harman Kardon AVR 355 Service Manual

MAIN PCB ASSY
Ref. # Part Number Description Value
R966 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R967 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R968 CRD20TJ105T RES , CARBON 1M OHM 1/5W J
R969 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R986 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R987 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R988 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R989 CRD20TJ302T RES , CARBON 3K OHM 1/5W J
R991 CRD20TJ822T RES , CARBON 8.2K OHM 1/5W J
R992 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R998 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
CMYAVR355 HEAT SINK ASS'Y ASS'Y
CFNCF12825HSN FAN , MOTOR FAN
CHD1A012R SCREW , SPECIAL SCREW
CHD1A036R SCREW , SPECIAL SCREW
CHD3A012R SCREW , SPECIAL SCREW
CMD1A398 BRACKET , PCB BRACKET
CMD1A417 BRACKET , PCB BRACKET
CMD1A600 BRACKET , FAN BRACKET
CMD2A615 BRACKET , FAN BRACKET
CMY1A303 HEAT SINK HEAT SINK
CMY2A249 HEAT SINK HEAT SINK
CTB3+10JR SCREW SCREW
CTB3+8JR SCREW SCREW
CTW3+8JR SCREW SCREW
Q652 HVT2SB1647-OKM T.R , POWER TR
Q653 HVT2SB1647-OKM T.R , POWER TR
Q654 HVT2SB1647-OKM T.R , POWER TR
Q655 HVT2SB1647-OKM T.R , POWER TR
Q657 HVT2SD2560-OKM T.R , POWER TR
Q658 HVT2SD2560-OKM T.R , POWER TR
Q659 HVT2SD2560-OKM T.R , POWER TR
Q660 HVT2SD2560-OKM T.R , POWER TR
Q661 HVT2SB1647-OKM T.R , POWER TR
Q670 HVT2SD2560-OKM T.R , POWER TR
Q803 HVT2SD2560-OKM T.R , POWER TR
Q804 HVT2SB1647-OKM T.R , POWER TR
Q805 HVT2SD2560-OKM T.R , POWER TR
Q807 HVT2SB1647-OKM T.R , POWER TR
CTW3+8JR SCREW SCREW
CWE8202150AA WIRE ASS'Y WIRE
C8AGB288 BOND (MAX) BOND
BN19 CWB3FE03250UP WIRE ASS'Y WIRE
BN20 CWB3FC04280UP WIRE ASS'Y WIRE
BN81 CWB1C902050EN WIRE ASS'Y WIRE
BN82 CWB1C902050EN WIRE ASS'Y WIRE
BN83 CWB1C902050EN WIRE ASS'Y WIRE
BN84 CWB1C902050EN WIRE ASS'Y WIRE
BN85 CWB1C902050EN WIRE ASS'Y WIRE
BN86 CWB1C902050EN WIRE ASS'Y WIRE
BN87 CWB1C902050EN WIRE ASS'Y WIRE
BN88 CWB2B905080EN WIRE ASS'Y WIRE
BN89 CWB1C902200EN WIRE ASS'Y WIRE
BN98 HJP08GA130ZK WAFER WAFER
BN99 CWB1C903280BM WIRE ASS'Y WIRE
CN11 CJP17GA117ZY WAFER WAFER
CN12 CJP21GA115ZY WAFER , CARD CABLE WAFER
CN61 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
CN62 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
CN63 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
harman/kardon
AVR 355/230 Service Manual
Page 23 of 125
