Harman Kardon AVR 355

MAIN PCB ASSY
Ref. # Part Number Description Value
CN64 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
CN65 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
CN66 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
CN67 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
CN89 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
CN90 CJP02GA89ZY WAFER WAFER
CN91 CJP02GA89ZY WAFER WAFER
CN92 CJP02KA060ZY WAFER WAFER
CN93 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
C563 CCEA1CH101T CAP , ELECT 100UF 16V
C631 CCEA1JH221E CAP , ELECT 220UF 63V
C632 CCEA1JH221E CAP , ELECT 220UF 63V
C633 CCEA1JH221E CAP , ELECT 220UF 63V
C634 CCEA1JH221E CAP , ELECT 220UF 63V
C635 CCEA1JH221E CAP , ELECT 220UF 63V
C636 CCEA1JH221E CAP , ELECT 220UF 63V
C637 CCEA1JH221E CAP , ELECT 220UF 63V
C638 CCEA1JH221E CAP , ELECT 220UF 63V
C639 CCEA1JH221E CAP , ELECT 220UF 63V
C640 CCEA1JH221E CAP , ELECT 220UF 63V
C807 CCEA1JH221E CAP , ELECT 220UF 63V
C808 CCEA1JH221E CAP , ELECT 220UF 63V
C809 CCEA1JH221E CAP , ELECT 220UF 63V
C810 CCEA1JH221E CAP , ELECT 220UF 63V
C902 CCET63VKL5822NK CAP , ELECT 8200/63V (30*50)
C904 KCKDKS472ME CAP , CERAMIC(X1/Y2/SC) 0.0047UF/2.5KV
C906 CCEA1VH102E CAP , ELECT 1000UF 35V
C909 CCET63VKL5822NK CAP , ELECT 8200/63V (30*50)
C911 CCEA1EH471E CAP , ELECT 470UF/25V
C915 CCET63VKL5123NK CAP , ELECT 12000/63V (35*45)
C916 CCET63VKL5123NK CAP , ELECT 12000/63V (35*45)
ET01 CMD1A387 BRACKET , PCB BRACKET
IC94 HVIKIA7805API REGULATOR, +5V KEC(KIA7805API)
JK91 CJJ5R006Z TERMINAL , SPEAKER TERMINAL
JK92 CJJ5Q012Z TERMINAL , SPEAKER TERMINAL
JK97 CJJ4P041W JACK IN/OUT JACK
JK98 CJJ4P042W JACK IN/OUT JACK
JW90 CWE8212120VV WIRE , RED WIRE
JW91 CWE8212180VV WIRE ASS'Y WIRE
JW93 CWEE202110VV WIRE (BLACK) WIRE
L501 CLEY0R5KAK COIL , SPEAKER 0.5UH K
L502 CLEY0R5KAK COIL , SPEAKER 0.5UH K
L503 CLEY0R5KAK COIL , SPEAKER 0.5UH K
L504 CLEY0R5KAK COIL , SPEAKER 0.5UH K
L505 CLEY0R5KAK COIL , SPEAKER 0.5UH K
L506 CLEY0R5KAK COIL , SPEAKER 0.5UH K
L507 CLEY0R5KAK COIL , SPEAKER 0.5UH K
OL91 KJJ7A022Z OUTLET , AC(EUR/1P) A302D0061P
Q858 HVT2SA1360O T.R 2SA1360O
Q871 HVT2SA1360O T.R 2SA1360O
Q872 HVT2SA1360O T.R 2SA1360O
Q874 HVT2SA1360O T.R 2SA1360O
Q875 HVT2SA1360O T.R 2SA1360O
Q876 HVT2SA1360O T.R 2SA1360O
Q877 HVT2SA1360O T.R 2SA1360O
Q881 HVT2SC3423O T.R 2SC3423O
Q882 HVT2SC3423O T.R 2SC3423O
Q883 HVT2SC3423O T.R 2SC3423O
Q884 HVT2SC3423O T.R 2SC3423O
Q885 HVT2SC3423O T.R 2SC3423O
