MAIN PCB ASSY
Ref. # Part Number Description Value
Q886 HVT2SC3423O T.R 2SC3423O
Q887 HVT2SC3423O T.R 2SC3423O
RY94 HSL1A008ZE RELAY SDT-S-112DMR
R656 CRF5EKR27HX2K RES , CEMENT 0.27ohm X 2
R657 CRF5EKR27HX2K RES , CEMENT 0.27ohm X 2
R658 CRF5EKR27HX2K RES , CEMENT 0.27ohm X 2
R659 CRF5EKR27HX2K RES , CEMENT 0.27ohm X 2
R660 CRF5EKR27HX2K RES , CEMENT 0.27ohm X 2
R810 CRF5EKR27HX2K RES , CEMENT 0.27ohm X 2
R811 CRF5EKR27HX2K RES , CEMENT 0.27ohm X 2
R905 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
R911 CRG1ANJ680H RES , METAL OXIDE FILM 68 OHM 1W J
R922 CRG1ANJ680H RES , METAL OXIDE FILM 68 OHM 1W J
R990 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
R993 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
R994 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
R995 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
R996 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
R997 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
R999 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
TH91 KRTP42T7D330B THERMAL SENSOR , POSISTOR P42T7D330BW20
T902 CLT5J039ZE TRANS , SUB AVR355 TRANS
POWER PCB ASSY
Ref. # Part Number Description Value
COP12027J AVR355/230 POWER PCB ASS'Y ASS'Y
C104 CCBS1E103ZFT CAP , CERAMIC 0.01UF 25V
C105 CCBS1E103ZFT CAP , CERAMIC 0.01UF 25V
C106 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C107 CCBS1E103ZFT CAP , CERAMIC 0.01UF 25V
C108 CCBS1E103ZFT CAP , CERAMIC 0.01UF 25V
C109 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C117 CCEA1HH4R7T CAP , ELECT 4.7UF 50V
C118 CCBS1E103ZFT CAP , CERAMIC 0.01UF 25V
C119 CCEA1JH470TS CAP , ELECT 63V/47UF/105'C
C120 CCEA1JH470TS CAP , ELECT 63V/47UF/105'C
C121 CCBS1E103ZFT CAP , CERAMIC 0.01UF 25V
C127 CCFT1H473ZF CAP , CERAMIC 0.047UF 50V Z
C131 CCEA1HH3R3T CAP , ELECT 3.3UF 50V
C750 CCEA1CH101T CAP , ELECT 100UF 16V
C751 CCEA1CH101T CAP , ELECT 100UF 16V
C752 CCEA1CH101T CAP , ELECT 100UF 16V
C851 CCEA1HH100T CAP , ELECT 10UF 50V
C852 CCEA1HH100T CAP , ELECT 10UF 50V
C853 CCEA1HH100T CAP , ELECT 10UF 50V
C854 CCEA1HH100T CAP , ELECT 10UF 50V
C855 CCEA1HH100T CAP , ELECT 10UF 50V
C856 CCEA1HH100T CAP , ELECT 10UF 50V
C857 CCEA1HH100T CAP , ELECT 10UF 50V
C911 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V SMALL SIZE
C912 CCEA0JH102T CAP , ELECT 1000UF 6.3V
C919 CCKT1H102KB CAP , CERAMIC 1000PF 50V K
C920 CCEA1HH470T CAP , ELECT 47UF 50V
C921 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J
C922 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J
C923 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J
C924 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J
C925 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C926 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C927 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
