POWER PCB ASSY
Ref. # Part Number Description Value
C928 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C931 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C932 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C933 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C934 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C935 CCBS1H223ZFT CAP , CERAMIC 0.022UF 50V
C936 CCBS1H223ZFT CAP , CERAMIC 0.022UF 50V
C937 CCBS1H223ZFT CAP , CERAMIC 0.022UF 50V
C938 CCEA1CH101T CAP , ELECT 100UF 16V
C939 CCEA1EH101T CAP , ELECT 100UF 25V
C940 CCEA1EH101T CAP , ELECT 100UF 25V
C947 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C948 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C949 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C953 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C954 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C957 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C971 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C977 CCFT1H103ZF CAP , CERAMIC 0.01UF 50V Z
D101 CVDZJ15BT DIODE , ZENER ZJ15B 1/2W
D102 HVDMTZJ27BT DIODE , ZENER MTZJ27B 1/2W
D104 CVD1N4003ST DIODE , RECT 1N4003
D105 CVD1N4003ST DIODE , RECT 1N4003
D108 CVD1N4003ST DIODE , RECT 1N4003
D109 CVDZJ8.2BT DIODE , ZENER ZJ8.2B 1/2W
D111 CVDZJ8.2BT DIODE , ZENER ZJ8.2B 1/2W
D114 CVD1N4003ST DIODE , RECT 1N4003
D115 CVD1N4003ST DIODE , RECT 1N4003
D116 CVD1N4003ST DIODE , RECT 1N4003
D117 CVD1N4003ST DIODE , RECT 1N4003
D124 CVD1N4003ST DIODE , RECT 1N4003
D125 CVD1N4003ST DIODE , RECT 1N4003
D201 CVDZJ3.3BT DIODE , ZENER ZJ3.3B 1/2W
D801 CVD1SS133MT DIODE 1SS133
D802 CVD1SS133MT DIODE 1SS133
D921 CVD1SS133MT DIODE 1SS133
D950 CVD1N4003ST DIODE , RECT 1N4003
D951 CVD1N4003ST DIODE , RECT 1N4003
F110 KBA2D2500TLET FUSE(SR-5,2.5A,250V) SAVE FUSETECH
F111 KBA2D2500TLET FUSE(SR-5,2.5A,250V) SAVE FUSETECH
Q104 HVTKSC2316YT T.R KSC2316Y
Q911 HVTKTA1267YT T.R KTA1267Y
Q912 HVTKTC3198YT T.R KTC3198Y
Q913 HVTKTC3198YT T.R KTC3198Y
Q995 HVTKRA107MT T.R KRA107M
Q997 HVTKRC107MT T.R KRC107M
R101 CRD25FJ3R3T RES , CARBON 3.3 OHM 1/4W J
R108 CRD20TJ8R2T RES , CARBON 8.2 OHM 1/5W J
R109 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R110 CRD20TJ8R2T RES , CARBON 8.2 OHM 1/5W J
R112 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R113 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R120 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R121 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R122 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R750 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R751 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R752 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R874 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R875 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
harman/kardon
AVR 355/230 Service Manual
Page 26 of 125
