POWER PCB ASSY
Ref. # Part Number Description Value
R876 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R877 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R878 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R879 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R880 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R882 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R883 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R884 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R885 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R886 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R887 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R888 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R891 CRD20TJ391T RES , CARBON 390 OHM 1/5W J
R892 CRD20TJ391T RES , CARBON 390 OHM 1/5W J
R893 CRD20TJ391T RES , CARBON 390 OHM 1/5W J
R894 CRD20TJ391T RES , CARBON 390 OHM 1/5W J
R895 CRD20TJ391T RES , CARBON 390 OHM 1/5W J
R896 CRD20TJ391T RES , CARBON 390 OHM 1/5W J
R897 CRD20TJ391T RES , CARBON 390 OHM 1/5W J
R901 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R912 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R913 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R917 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R918 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R919 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R920 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R921 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R922 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R923 CRD25TJ153T RES , CARBON 15K OHM 1/4W J
R924 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R925 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R926 CRD25TJ103T RES , CARBON 10K OHM 1/4W J
R927 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R928 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R941 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R942 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R956 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J
R957 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R970 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R971 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R972 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R973 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R974 CRD20TJ271T RES , CARBON 270 OHM 1/5W J
R975 CRD20TJ271T RES , CARBON 270 OHM 1/5W J
R976 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R977 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
VR81 CVN1RA221B02T RES , SEMI FIXED (220, B CURVE) KVSF637AVC
VR82 CVN1RA221B02T RES , SEMI FIXED (220, B CURVE) KVSF637AVC
VR83 CVN1RA221B02T RES , SEMI FIXED (220, B CURVE) KVSF637AVC
VR84 CVN1RA221B02T RES , SEMI FIXED (220, B CURVE) KVSF637AVC
VR85 CVN1RA221B02T RES , SEMI FIXED (220, B CURVE) KVSF637AVC
VR86 CVN1RA221B02T RES , SEMI FIXED (220, B CURVE) KVSF637AVC
VR87 CVN1RA221B02T RES , SEMI FIXED (220, B CURVE) KVSF637AVC
CMD1A618 BRACKET , RESET BRACKET
BN17 CJP06GB143ZB FEMALE HEADER(6P, 2.54mm) HEADER
BN20 CWB1C905180BM WIRE ASS'Y WIRE
BN21 CWB1C905120EN WIRE ASS'Y WIRE
BN22 CWB1C902280NN WIRE ASS'Y WIRE
BN79 CWB1C907120EN WIRE ASS'Y(7P, 2MM, 120MM) WIRE
BN80 CWB2B903180EN WIRE ASS'Y WIRE
harman/kardon
AVR 355/230 Service Manual
Page 27 of 125
