Harman Kardon AVR 430 - Page 29

AVR430/230 PROCESSOR PCB 5/11
POS PART NAME PART NUMBER
J39 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J40 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J41 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J7 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J8 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J9 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
JR317 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
N2 CONN 2.0MM 19 MA R NAT SOCKET MOLEX 35237-1910 0 0 H01-WN19AB00000
NJ51 JACK RCA 4P JB040131PN WWRR H01-SORA40GNDNN
NJ52 JACK RCA 4P JB040131PN WWRR H01-SORA40GNDNN
NJ53 JACK RCA 4P JB040131PN WWRR H01-SORA40GNDNN
NJ54 JACK RCA 4P JB040131PN WWRR H01-SORA40GNDNN
NJ55 JACK RCA 4P JB040131PN WWRR H01-SORA40GNDNN
NP7 CONN 2.0MM 19 MA R NAT SOCKET MOLEX 35237-1910 0 0 H01-WN19AB00000
P1 CONN 2.0MM 4 MA ST NAT GT201-4P-TS H01-WN04SB00000
P10 CONN 2.0MM 8 MA ST NAT GT201-8P-TS H01-WN08SB00000
P12 CONN 2.0MM 4 MA ST NAT GT201-4P-TS H01-WN04SB00000
P13 CONN 2.0MM 3 MA ST NAT GT201-3P-TS H01-WN03SB00000
P2 CONN 2.0MM 11 MA R NAT SOCKET MOLEX 35237-1110 0 0 H01-WN11AB00000
P20 WIRECONASY DL 2.0MM 02P 75MM ANG UL1007 RIBBON 26 1 B2011H02 H01-WC2260755CG
P20-1 WIRECONASY DL 2.0MM 02P 75MM ANG UL1007 RIBBON 26 1 B2011H02 H01-WC2260755CG
P3 CONN 2.0MM 4 MA ST NAT GT201-4P-TS H01-WN04SB00000
P4 CONN 2.0MM 6 MA ST NAT GT201-6P-TS H01-WN06SB00000
P6 CONN 2.0MM 17 MA R NAT SOCKET MOLEX 35237-1710 0 0 H01-WN17AB00000
P9 CONN 2.0MM 15 MA ST NAT GT201-15P-TS H01-WN15SB00000
Q1 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q10 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q11 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q12 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q13 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI
Q14 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI
Q15 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q16 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q17 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI
Q19 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q2 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q20 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI
Q23 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI
Q24 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q25 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI
Q26 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q27 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q28 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q29 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q3 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI
Q30 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q31 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q32 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI
Q33 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q34 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI
Q35 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI
Q36 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q37 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI
Q38 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q39 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q4 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q40 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q41 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI
Q42 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q43 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI
Q44 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q45 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q46 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q50 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI
Q54 TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM H01-TRDTC114YNI
Q58 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
