AVR430/230 1/2
NO. PART NUMBER PART NAME Q'TY
1 H01-ZPC1022GABT WINDOW DISPLAY AVR430 1
2 H01-ZPC1020GACR CAP KNOB VOLUME AVR430/630 1
3 ZPC1021GA00 COVER KNOB VOLUME AVR430/630 1
4 H01-ZPC1018GART FILTER DISPLAY AVR430/630 1
5 H01-ZMC11S00200 AL DOOR AVR430/630 1
6 H01-ZMC11S00300 AL PANEL AVR430/630 1
7
8 H01-ZMC11S04A00 BKT HINGE AVR430/630 2
9 ZPC1002GA00 DOOR AVR430/630 1
10 ZPC1001GA00 PANEL FRONT AVR430/630 1
11 H01-ZMC11S12A00 CAP BUTTON STAND-BY AVR430/630 1
12 ZPC1007GA00 INDICATOR STAND-BY 1
13 ZPC1003GA00 BUTTON POWER 1
14 ZPC1006GA00 BUTTON STANDBY 1
15 H01-SWA2B21PDA SW PUSH POWER SDDLB15700 1
16 H01-ZMB01S00100 BKT HEADPHONE 1
17 H01-SOSS9CKX3NN JACK PHONE 6.35 H70980110S 9P BK 1
18 H01-VDHCA18LL03 FL HCA-18LL03 3
19 ZPC1102GACR INDICATOR VIDEO 4 2
20 ZPC1005GA00 BUTTON 8 KEY 1
21 H01-ZMC12S20A00 BADGE AL HARMAN/KARDON SILVER 1
22 H01-ICTORX179XX IC-REMOTE TORX179 FIBER OPTIC RECEIVER SHUTTER TYPE 4
23 H01-SORA1JE01NN JACK RCA 1P JE010003MN GND OR 1
24 H01-ZMC12S17A00 AC PUN SHIELD DIGITAL ET 1
25 H01-ZPD0104GASG BUTTON 7 KEY EU 1
26 ZFNR19720SB RUBBER FOOT 19.7X19.7X2T BK 4
27 ZPC1103GAGY FOOT 50MM 15.8MM 4
28 H01-ZMC11S13A00 CHASSIS MAIN AVR430/630 1
29 H01-SORA8OSC5N8 CON DIN SCKT SOCKET CONNECTOR SVHS EST-S408J 1
30 H01-SWE3A0505S1 SWIROT EC16B24204 5V 500U0A 10T 3P 0 0 1
31 ZPC1017GA00 HOLDER VFD AVR430/630 1
32 H01-ICRPM6938NN IC-REMOTE RPM6938-RSIP-A3 RECEIVER 38KHZ 1
33 H01-ZMC11S07A00 CHASSIS FRONT AVR430/630 1
34 H01-TX-PWMM630B0 MN X'FORMER AVR630 120V 1
35 H01-ZMC12S08B00 BKT TRANS BOTTOM 1
36 H01-ZMC11S09A00 BKT FAN FRONT AVR430/630 1
37 H01-ZVC11FAN100 FAN JF0925S1L 1
38 H01-ZMC11S04B00 BKT FRAME GUIDE 2
39 ZMC12S14AYE STANDOFF HEX M4X0.7 6X61.9H 3
40 H01-ZMC12HS0300 H/SINK REG 118*20* 1
41 H01-SORA44104NN CON PHONO SCKT RCA 4P JW-4104RSA 1
42 H01-SORA40RSCNN CON PHONO SCKT RCA 4P JW-4104RSC 1
43 H01-SO0A18P8CNN JACK-TELE SNAP-IN GOLDEN TELECOM GDL1-8P8C 8T BK 0 0 1
44 H01-SOPA81900NN CONN-SPE TERMINAL SPKR 8P SH081136JP FE 19MM 8 -- 0 0 1
45 ZMC12S13AYE STANDOFF HEX M4X0.7 6X31.9H 3
46 H01-SORA40GNDNN CON PHONO SCKT RCA 4P JW4104RS GND 5
47 H01-ZVD01TUNE00 TUNER MODULE KST-MB114MW1-81 OEM EU 1
48 H01-ZMC11HS0200 H/SINK MAIN AVR630 1
49 H01-ZMC12HS0100 AC HEATSINK 17*15*30 AVR520 -- ME 1
50 ZMC12S15AYE STANDOFF HEX M4X0.7 6X111.2H 1
51 H01-ZMC12S19A00 BKT INLET 2
52 H01-SOXA27014NN CON MAINS INLET A/C INLET 7014-NGP 1
53 H01-SOPA21275BK CONN-SPE AC OUTLET 2P 110V FE 12.75MM 2 BK 0 0 1
54 H01-ZMC11HS0100 H/SINK AMP AVR630 1
55 H01-ZMC12S09A00 BKT HEATSINK 6
56 H01-SOPA619BKNN CONN-SPE TERMINAL SPKR 6P SH0611708P FE 19MM 6 BK 0 0 1
57 H01-SOPA96063NN JACK D-SUB 9P 87204-6063 W/DUST COVER BK 1
58 H01-SOJW2350SNN JACK PHONE 3.6 EP-1401A 1P BK 3
59 H01-ZMC12S16A00 AC PUN BRACKET BKT GROUND ET 0.5T AVR520 -- 1
60 H01-ZMC11S10A00 BKT FAN REAR AVR430/630 1
61 H01-SORA21502NN CON PHONO SCKT RCA 2P W/GNDCAP JW-1502SN OO 1
62 ZPC1016GA00 KNOB VOLUME AVR430/630 1
63 H01-SORA103LNNN CON PHONO SCKT RCA 1P W/GND JE010003LN OG 1
64 H01-SORA11Y00NN JACK RCA+S VIDEO CC5016031DN GNDCAP Y 7
65 H01-ZMD01S01A00 PANEL REAR AVR430EU 1
66 H01-ZMC11S08A00 COVER TOP AVR430/630 1
EXPLODED VIEW PART LIST
