AVR430/630 Alignment spec.
rev01.
1. MAIN B'D
: 5 Min. After power on, please set up Bias as below,
Front Left > use VR71, set P801 as 23mV +2mV/- 1mV.
Surr Left > use VR73 then set P803 as 23mV +2mv/-1mV.
Front Right > use VR72 make P802 to 23mV +2mV/-1mV.
Surr Right > use VR73 then make P804 to 23mV +2mV/-1mV.
P801 FRONT L-CH P803 SURROUND L-CH
