Rear Panel Video Connections
7
ENGLISH
A VCR 1 Audio In: Connect these
jacks to the audio PLAY/OUT jacks of
a VCR.
B VCR 1 Audio Out: Connect these
jacks to the RECORD/IN audio jacks
of a VCR.
C VCR 1 Video In: Connect this jack
to the composite video PLAY/OUT
jack of a VCR.
D VCR 1 Video Out: Connect this
jack to the composite video
RECORD/IN jack of a VCR.
E VCR 1 S Video Out: Connect this
jack to the “S” video RECORD/IN jack
of a VCR.
F VCR 1 S Video In: Connect this
jack to the “S” video PLAY/OUT jack
of a VCR.
G VCR 2 Audio In: Connect these
jacks to the audio jacks PLAY/OUT of
a second VCR.
H VCR 2 Audio Out: Connect these
jacks to the audio RECORD/IN jacks
of a second VCR.
I VCR 2 Video In: Connect this jack
to the composite video PLAY/OUT
jack of a second VCR.
J VCR 2 Video Out: Connect this
jack to the composite video
RECORD/IN jack of a second VCR.
K TV Audio In: Connect the audio
outputs of a TV, cable converter or
satellite receiver to these jacks.
L TV Video In: Connect the
composite video output of a TV, cable
converter or satellite receiver to this
jack. The signals received at this jack
are also used to trigger the “TV Auto-
On” feature.
M LD Audio In: Connect the audio
output of a laser disc player to these
jacks.
N LD Video In: Connect the
composite video output of a laser disc
player to this jack.
O LD S Video In: Connect the “S”
video output of a laser disc player to
this jack.
P TV Monitor Video Out: Connect
this jack to the composite video input
of a TV monitor or video projector to
view the on screen control menus and
output of the receiver’s video switcher.
Q TV Monitor S Video Out:
Connect this jack to the S video input
of a TV monitor or video projector to
view S video sources selected by the
receiver’s video switcher.
AVR70 engelsk manual 11/01/98 11:57 Side 7
