AVR 700/AVR 70/AVR 70C
20
Specifications
Specifications
Audio Section
Multichannel power: 75W per channel, two
channels driven @ 6
ohms, 20Hz – 20kHz,
<0.1% THD;
100W per channel, two
channels driven @ 6
ohms, 1kHz, <1% THD
Input sensitivity/impedance: 200mV/47k ohms
Signal-to-noise ratio (IHF-A): 95dB
Surround system adjacent-channel separation: Dolby Pro Logic/PLII:
40dB
Dolby Digital: 55dB
DTS: 55dB
Frequency response: 10Hz – 100kHz
High instantaneous-current capability (HCC): ±25 amps
FM Tuner Section
Frequency range: 87.5 – 108.0MHz
Usable sensitivity IHF: 1.3µV/13.2dBf
Signal-to-noise ratio (mono/stereo): 65dB/62dB
Distortion (mono/stereo): 0.2%/0.3%
Stereo separation: 35dB @ 1kHz
Image rejection: 80dB
IF rejection: 80dB
AM Tuner Section
Frequency range: 520 – 1720kHz
Signal-to-noise ratio: 45dB
Usable sensitivity (loop): 500µV
Selectivity (±10kHz): 30dB
Video Section
Television format: NTSC (AVR 700);
PAL (AVR 70/AVR 70C)
Input level/impedance: 1Vp-p/75 ohms
Output level/impedance: 1Vp-p/75 ohms
Video frequency response (composite video): 10Hz – 8MHz (–3dB)
HDMI: With 3D and Deep Color
General Specifications
Power requirement: 120V AC/60Hz (AVR 700)
220V AC/50Hz (AVR 70)
230V AC/50Hz (AVR 70C)
Power consumption: <0.5W (standby);
280W maximum
Dimensions (W x H x D): 17-5/16" x 4-5/16" x 13"
(440mm x 125mm x 330mm)
Weight 20 lb (9.1kg)
