Harman Kardon AVR 745 Brochure

Model AVR 745 AVR 645 AVR 445 AVR 340 AVR 240 AVR 140
Description 7.2-Channel AVR 7.1-Channel AVR 7.1-Channel AVR 7.1-Channel AVR 7.1-Channel AVR 6.1-Channel AVR
Stereo Power (FTC) 100 x 2 90 x 2 80 x 2 70 x 2 65 x 2 50 x 2
Multichannel Power (FTC) 85 x 7* 75 x 7* 65 x 7* 55 x 7* 50 x 7* 40 x 6*
A
mplifier Type High current High current High current High current High current High current
±60 amps ±50 amps ±40 amps ±35 amps ±35 amps ±25 amps
THD @ Impedance 0.07% @ 8 ohms 0.07% @ 8 ohms 0.07% @ 8 ohms 0.07% @ 8 ohms 0.07% @ 8 ohms 0.07% @ 8 ohms
Bandwidth 20Hz – 20kHz 20Hz – 20kHz 20Hz – 20kHz 20Hz – 20kHz 20Hz – 20kHz 20Hz – 20kHz
B
andwidth @ 1W 10Hz – 130kHz 10Hz – 130kHz 10Hz – 130kHz 10Hz – 130kHz 10Hz – 130kHz 10Hz – 130kHz
(+0dB/–3dB)
Signal-to-Noise Ratio 100dB 100dB 100dB 100dB 100dB 100dB
(IHF-A)
Power Supply Independent front & rear Independent front & rear Independent front & rear Independent front & rear Independent front & rear Independent front & rear
Dolby
®
Digital Dolby
®
Digital EX Dolby
®
Digital EX Dolby
®
Digital EX Dolby
®
Digital EX Dolby
®
Digital EX Dolby
®
Digital EX
Dolby
®
Pro Logic
®
II Pro Logic
®
IIx Pro Logic
®
IIx Pro Logic
®
IIx Pro Logic
®
IIx Pro Logic
®
IIx Pro Logic
®
IIx
Dolby
®
Virtual Speaker Yes Yes Yes Yes Yes No
DTS
®
5.1 Yes Yes Yes Yes Yes Yes
DTS-ES
®
6.1 Yes Yes Yes Yes Yes Yes
Discrete & Matrix
DTS 96/24
®
Yes Yes Yes Yes Yes Yes
DTS Neo:6
®
Yes Yes Yes Yes Yes Yes
Logic 7
®
Yes Yes Yes Yes Yes Yes
VMAx
®
No No No Yes Yes Yes
Headphone Modes 2-Channel, Dolby
®
HP 2-Channel, Dolby
®
HP 2-Channel, Dolby
®
HP 2-Channel, Dolby
®
HP 2-Channel, Dolby
®
HP 2-Channel
XM-Ready
®
Yes Yes Yes No No No
Multizone Capability Audio/video, with remote Audio, with remote Audio, with remote Audio, with remote No No
Assignable Rear-Channel Yes Yes Yes Yes No No
Amplifiers
A-BUS/READY
®
2
Yes Yes Yes Yes No No
EzSet Capability EzSet/EQ II EzSet/EQ EzSet/EQ EzSet/EQ EzSet+ No
* All channels operating at full power.
Model (continued) AVR 745 AVR 645 AVR 445 AVR 340 AVR 240 AVR 140
A/V Inputs 5 5 5 5 5 4
S-Video Inputs 5 5 5 5 5 4
Analog Audio Inputs 4 4 4 4 4 4
D
igital Audio Inputs Rear panel 3/3/1 Rear panel 3/3/1 Rear panel 3/3/1 Rear panel 3/3/0 Rear panel 2/2/0 Rear panel 2/2/0
(Coax/Optical/USB
3
) Front panel 1/1/0 Front panel 1/1/0 Front panel 1/1/0 Front panel 1/1/0 Front panel 1/1/0 Front panel 1/1/0
Digital Audio Outputs Rear panel 1/1 Rear panel 1/1 Rear panel 1/1 Rear panel 1/1 Rear panel 1/1 Rear panel 1/1
(Coax/Optical) Front panel 1/0 Front panel 1/0
Digital Input Polling All video inputs All video inputs All video inputs All video inputs All video inputs All video inputs
Direct Audio Inputs 7.1 With bass management 7.1 7.1 7.1 7.1 7.1
HDMI
™
Inputs/Output 2/1 2/1 2/1 0 0 0
HDMI
™
Type 1.1 With audio/video processing 1.1 With audio processing Switching N/A N/A N/A
Preamp Outputs 7.2 Channels 7.1 Channels 7.1 Channels 7.1 Channels 7.1 Channels Subwoofer
Component Video 3 @ 100MHz 2 @ 100MHz 2 @ 60MHz 2 @ 50MHz 2 @ 50MHz 2 @ 50MHz
Inputs (Assignable)
Bass Management Quad crossover Quad crossover Quad crossover Quad crossover Quad crossover Quad crossover
On-Screen Display Yes, including component Yes, including component Yes, including component Yes, including component Yes Yes
Input Titling All inputs All inputs All inputs All inputs All inputs All inputs
DSP Processor TI DA 610 TI DA 610 TI DA 610 Cirrus
®
CS 49400 Cirrus
®
CS 49400 Cirrus
®
CS 49400
Output DACs 192kHz/24-bit 192kHz/24-bit 192kHz/24-bit 192kHz/24-bit 192kHz/24-bit 192kHz/24-bit
Video Processing/ DCDi
®
by Faroudja Composite/S to component Composite/S to component Composite/S to component No No
Conversion scaling to 720p or 1080i cross conversion cross conversion cross conversion
A/V Sync Delay 200 mS 80 mS 80 mS 80 mS 80 mS No
IEC Detachable Power Cord Yes Yes Yes No No No
System Remote TC 30 activity-based, 9-Device learning & 9-Device learning & 9-Device programmable 9-Device programmable 8-Device programmable
color LCD, Internet programmability programmable with backlit, programmable with backlit,
two-line LCD two-line LCD
IR In/Out Jacks Yes Yes Yes Yes Yes No
IR Carrier Output Yes Yes Yes Yes No No
Discrete Remote On/Off Codes Yes Yes Yes Yes Yes Yes
Low-Voltage Trigger Jacks 2 1 1 No No No
External Data Port USB and RS-232 USB and RS-232 USB and RS-232 No No No
Speaker Terminals All-metal color-coded binding posts Color-coded binding posts Color-coded binding posts Color-coded binding posts Color-coded binding posts Color-coded binding posts
Dimensions
6-1/2" x 17-5/16" x 17-1/8" 6-1/2" x 17-5/16" x 17-1/8" 6-1/2" x 17-5/16" x 17-1/8" 5-15/16" x 17-5/16" x 13-13/16" 5-15/16" x 17-5/16" x 13-13/16" 5-15/16" x 17-5/16" x 13-13/16"
(H x W x D)
Weight 52 lb 41 lb 39 lb 24.4 lb 24.4 lb 24.4 lb
Model The Bridge
Description iPod
®1
Docking Station
iPod
®
Requirements iPod
®
with docking connector
(not compatible with iPod shuffle
™
)
Receiver Requirements Harman Kardon
®
AVR (AVR 40 Series or AVR 45 Series)
with DMP/The Bridge docking connector
Audio Compatibility AVR’s analog outputs, including multiroom and A-BUS
®
outputs
and recording outputs
Dimensions (H x
W x D)
1-3/16" x 4-1/2" x 4-1/2"
W
eight 5.9 Ounces
Model TC 30
Description Activity-Based Remote
LCD Screen 64K color LCD
Maximum Devices 15
Maximum Activities 255
Memory 2MB
Computer Requirements PC with Microsoft
®
Windows
®
98SE/ME/2000/XP or Mac OS
®
X,
CD-ROM drive, USB port (dial-up or broadband Internet access required for programming)
Includes TC 30, installation disc, USB cable, lithium-ion rechargeable battery,
charging cradle, AC adapter, power supply
Remote Dimensions (H x W x D) 8-7/8" x 2-1/8" x 1"
Charging Cradle Dimensions (H x W x D) 8-13/16" x 2-3/8" x 11/16"
Remote Weight 6 Ounces
Charging Cradle Weight 5 Ounces
Model AB 1
Description A-BUS/READ
Y
®
In-Wall Module With Built-In Amplifier
System Requirements Any Harman Kardon
®
A-BUS/READY
®
receiver,
or any receiver or source product connected to
an ABH 4. Connections via Cat. 5/5e cable.
Use with 6-ohm or 8-ohm speakers with
sensitivity >88dB. Includes IR sensor for
pass-through of remote commands.
Dimensions (H x W x D) 4-1/4" x 1-3/4" x 2-1/4"
Weight 0.25 lb
Model HE 1000
Description External Infrared Remote Sensor
System Requirements Harman Kardon
®
or compatible products
with “IR Remote In” jack
Includes
P
ower supply
,
connecting block,
connecting cable
Unit Dimensions (H x W x D) 1" x 3-5/16" x 2-5/16"
Unit
W
eight 5.7 Ounces
Model ABH 4
Description 4-Room A-BUS
®
Expansion Hub
System Requirements AB 1 or other compatible A-BUS
®
modules.
Harman Kardon
®
A-BUS/READY
®
receiver
or any source device with standard analog
L/R outputs.
Dimensions (H x W x D) ABH 4: 3-5/16" x 7-3/16" x 1-3/16"
P
ower Supply:
1-7/16" x 5-15/16" x 2-13/16"
W
eight
ABH 4:
0.9 lb
Power Supply: 1 lb
SPECIFICATIONS
34 35
