Specifications
15
ENGLISH
Stereo Mode
Continuous Average Power (FTC)
40Watts from 20Hz-20kHz: @<0.09% THD,
both channels
driven into 8 Ohms
Five Channel Surround Mode
Continuous average power per channel (FTC)
Front L&R channels
2x40Watts from 20Hz-20kHz: @<0.2% THD,
both channels
driven into 8 Ohms
Center channel
45 Watts at 1kHz: @<0.9% THD,
driven into 8 Ohms
Rear channels
2 x 22,5 Watts at 1kHz: @<1.0% THD,
both channels
driven into 4 Ohms
Amplifier Section
High-Instantaneous Current Capability
(HCC): ±20 Amps
Negative Feedback: 26dB
Frequency Response
@1W (+0/–3dB): 5Hz–120kHz
Rise Time: 1.8µSec
Transient Intermodulation
Distortion (TIM): Unmeasurable
Preamplifier Section
Signal-to-Noise Ratio (ref. 35 Watts, A-Wtd)
CD: 95dB
Video: 85dB
Input Sensitivity/Impedance
Video, CD, Tape: 150mV/22kOhms
Tone Control Range
Bass @ 50Hz: ±10dB
Treble @ 10kHz: ±10dB
Tuner Section: FM
Usable Sensitivity, Mono (dBf): < 14.2
46dB Quieting Sensitivity,
Stereo (dbf): < 49.3
Signal-to-Noise Ratio (IHF)
@ 65dBf, mono/stereo: > 65dB/62dB (DIN)
Capture Ratio: < 2.0dB
Selectivity, Adjacent/Alternate
Channel (150/300 kHz): > 5dB/65dB
IF Rejection: 90dB
AM Rejection @ 45dBf: 50dB
Stereo Separation
@ 1kHz, 65dBf: > 35dB
THD @ 1kHz, 65dBf,
mono/stereo (%): < 0.3/0.5
Tuner Section: AM
Sensitivity, External Antenna: < 500µV/m
Alternate Channel Selectivity: >25dB
Image Rejection: >35dB
IF Rejection: >50dB
General
Dimensions (WxHxD):
mm: 440 x 142 x 360
Weight (kgs/lbs): 8.2 kg, 18 lbs
Depth measurement includes knobs, buttons and jacks.
Height measurement includes feet.
All features and specifications are subject to change without notice.
Manufactured under license from Dolby Laboratories Licensing Corporation. Additionally
licensed under one or more of the following patents: U.S. number 3,959,590; Canadian
numbers 1,004,603 and 1,037,877. “Dolby”, “Pro Logic” and the double-D symbol are
trademarks of Dolby Laboratories Licensing Corporation.
AVR11 engelsk manual 11/01/98 10:46 Side 15
