Harman Kardon AVR130 Service Manual

Ref. Designator Part Number Description
FRONT PCB ASS'Y
C806 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C807 CCKT1H104ZF CAP , CERAMIC 50V 0.1UF
C808 CCKT1H181KB CAP , CERAMIC 180PF 50V KB
C809 HCEA1AH471T CAP , ELECT 470UF 10V
C810 HCEA1CH101T CAP , ELECT 100UF 16V
C811 HCEA1CH101T CAP , ELECT 100UF 16V
C812 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C813 HCEA1HH4R7T CAP , ELECT 4.7UF 50V
C814 HCEA1HH4R7T CAP , ELECT 4.7UF 50V
C850 HCBS1H471KBT CAP , CERAMIC 470PF 50V
C851 HCBS1H471KBT CAP , CERAMIC 470PF 50V
C852 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C855 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C856 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C857 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C858 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C859 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C860 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C861 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C862 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C863 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C864 HCEA1VH100T CAP , ELECT 10UF 35V
C865 CCKT1H473ZF CAP , CERAMIC 0.047UF 50V ZF
C866 HCEA1CKS100T CAP , ELECT 10UF 16V
C867 HCEA1CKS100T CAP , ELECT 10UF 16V
C868 HCEA1CKS470T CAP, ELECT 47UF 16V
C869 HCEA1CKS470T CAP, ELECT 47UF 16V
C870 HCBS1H681KBT CAP , CERAMIC 680PF 50V
C871 HCBS1H681KBT CAP , CERAMIC 680PF 50V
C872 HCEA1CH331T CAP , ELECT 330UF 16V
C873 HCEA1CH331T CAP , ELECT 330UF 16V
C874 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C875 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z
C876 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z
C877 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z
C878 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z
C880 HCEA1AH221T CAP , ELECT 220UF 10V
C882 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C886 HCEA0JH102T CAP , ELECT 1000UF 6.3V
C889 HCBS1H220JT CAP , CERAMIC 22PF 50V
C890 HCBS1H220JT CAP , CERAMIC 22PF 50V
C891 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C892 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C893 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C894 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C895 HCEA1AH471T CAP , ELECT 470UF 10V
C896 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C897 HCEA1AH471T CAP , ELECT 470UF 10V
C900 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C853 KCKDKS472ME CAP , CERAMIC(X1/Y2/SC) 0.0047UF/2.5KV
Semiconductors
D724 HVD1SS133MT DIODE 1SS133T-77
D728 HVD1SS133MT DIODE 1SS133T-77
D729 HVD1SS133MT DIODE 1SS133T-77
D730 HVD1SS133MT DIODE 1SS133T-77
D761 HVD1SS133MT DIODE 1SS133T-77
D774 HVD1SS133MT DIODE 1SS133T-77
D775 HVD1SS133MT DIODE 1SS133T-77
D776 KVD1N4003ST DIODE 1N4003
AVR130 harman/kardon
27

Harman Kardon AVR130 Specifications

General

Signal-to-Noise Ratio	100dB
Total Harmonic Distortion	0.07%
Output Impedance	8 Ohms
Input Sensitivity	200mV
Input Impedance	47k Ohms
Tuner Presets	30
Frequency Response	10Hz to 100kHz
Inputs	1 x Coaxial Digital, 1 x Optical Digital
Outputs	1 x Audio
Dimensions	440 x 150 x 382 mm
