Harman Kardon AVR130 Service Manual

Ref. Designator Part Number Description
FRONT PCB ASS'Y
D777 HVD1SS133MT DIODE 1SS133T-77
D778 KVD1N4003ST DIODE 1N4003
D779 HVD1SS133MT DIODE 1SS133T-77
D783 HVD1SS133MT DIODE 1SS133T-77
D784 HVD1SS133MT DIODE 1SS133T-77
D785 HVD1SS133MT DIODE 1SS133T-77
D786 HVDMTZJ5.6BT DIODE , ZENER 5.6V ZENER
D787 HVDMTZJ5.6BT DIODE , ZENER 5.6V ZENER
IC87 HVIRE5VL28CATZ IC , RESET 2.8V I.C , RESET
Q701 HVTKRC107MT TRANSISTOR NPN KRC107M
Q702 HVTKRC107MT TRANSISTOR NPN KRC107M
Q703 HVTKRC107MT TRANSISTOR NPN KRC107M
Q705 HVTKRC107MT TRANSISTOR NPN KRC107M
Q706 HVTKRC107MT TRANSISTOR NPN KRC107M
Q722 HVTKRA107MT TRANSISTOR NPN KRA107M
Q724 HVTKRC107MT TRANSISTOR NPN KRC107M
Q725 HVTKRC107MT TRANSISTOR NPN KRC107M
Q726 HVTKRC107MT TRANSISTOR NPN KRC107M
Q727 HVTKRC107MT TRANSISTOR NPN KRC107M
Q728 HVTKRC107MT TRANSISTOR NPN KRC107M
Q729 HVTKRC107MT TRANSISTOR NPN KRC107M
Q734 HVTKTC2874BT TRANSISTOR , NPN, MUTE KTC2874B
Q735 HVTKTC2874BT TRANSISTOR , NPN, MUTE KTC2874B
Q736 HVTKTC2874BT TRANSISTOR , NPN, MUTE KTC2874B
Q737 HVTKTC2874BT TRANSISTOR , NPN, MUTE KTC2874B
Q738 HVTKRC107MT TRANSISTOR NPN KRC107M
Q739 HVTKTA1271YT TRANSISTOR PNP KTA1271Y
Q743 HVTKRA107MT TRANSISTOR NPN KRA107M
D702 CVD52CSBBCEAB2 BLUE L.E.D
D703 CVD52CSBBCEAB2 BLUE L.E.D
D704 CVD52CSBBCEAB2 BLUE L.E.D
D706 CVD52CSBBCEAB2 BLUE L.E.D
D707 CVD52CSBBCEAB2 BLUE L.E.D
D723 CVD50BOGDWGA L.E.D , 2 COLOR
IC72 BVIMB90F482APFG130 IC , FLASH U-COM FUJITSU
IC73 HRVRPM6938H4 SENSOR , REMOTE RPM6938-H4
IC74 HVIS3F84BB I.C , FLASH U-COM S3F84BB
IC75 HVI74ACT04MTR I.C , HEX
IC76 HVITC74HCU04AFN IC , INVERTER TC74HCU04AFN
IC80 HVIHCF4053M013T I.C S.T
IC81 HVINJM2068MDTE1 I.C , OP AMP NJM2068MD-TE1
IC82 HVINJM2068MDTE1 I.C , OP AMP NJM2068MD-TE1
IC83 HVI74ACT04MTR I.C , HEX
IC84 HVI74ACT04MTR I.C , HEX
IC85 HVIRH5VT18C I.C , RESET 1.8V I.C , RESET
IC86 HVINJM4556AL I.C NJM4556AL
IC88 HVINJM2068MDTE1 I.C , OP AMP NJM2068MD-TE1
Resistors
R701 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R702 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J
R704 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R705 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R706 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R707 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R708 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R709 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R710 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R711 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R712 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
AVR130 harman/kardon
28

Harman Kardon AVR130 Specifications

General

Signal-to-Noise Ratio	100dB
Total Harmonic Distortion	0.07%
Output Impedance	8 Ohms
Input Sensitivity	200mV
Input Impedance	47k Ohms
Tuner Presets	30
Frequency Response	10Hz to 100kHz
Inputs	1 x Coaxial Digital, 1 x Optical Digital
Outputs	1 x Audio
Dimensions	440 x 150 x 382 mm
